Modularity of the DOOR PHONE
-
The LINK DOOR PHONE Main Module UCxN is declined in 3 types UC2N, UC1N, UC0N (equiped
with 2, 1 or 0 direct call buttons)
-
It is possible to associat to Main module UCxN the following modules
-
IP or IP WiFi Camera module
-
A keypad (UCKN)
-
Up to 16 x 4 direct call buttons module C4N (Master) and M4N (Slave), by connecting behind each
C4N (Master) module a M4N (Slave) module
-
The whole DOOR PHONE can be installed
-
Embeded or Surface mounting
UC2N
UCKN
Fixing frame 2
Examples of frame configuration
All rights are reserved to Linkcom
UC1N
C4N (master)
SMB2N-rain-
protective cover
LINK DOOR PHONE
M4N (slave)
Flanging frame2
(flush-mounted)
classe
classement
LinkDoor
DR
– Installation and Operating Instructions
UC0N
IP Camera
WIFI Camera
MK-2
Number
date
15/04/05
001
page
4/31
