Parameter Value
Meaning
42
z
z – Sign for call extension * or # (10 sec before call end the Doorphone will send a signal, then the call may be
extended by dialing either * or # )
List of related parameters: 52 8# 84
Parameter Value
Meaning
43
g bb
g – Relay [1-2] (two commands in order to hang up the Doorphone using both Relays)
bb –
command for Doorphone hanging up from phone [2 digits]
It is recommanded to set the same prefix for Doorphone Relay activating (parameter 35) aa=bb.
List of related parameters: 35 8# 84
Parameter Value
Meaning
44
xxxx
xxxx
– Password for remote mode programming
List of related parameters: 8# 84
Parameter Value Meaning
45
dd
Switch on Day mode
46
nn
Switch on Night mode
dd – Prefix for DAY mode switching [2 digits]
nn – Prefix for NIGHT mode switching [2 digits]
Note: The Relay over Day/Night mode remains set in Doorphone even after line disconnection.
List of related parameters: 1 2 33 34 47 8# 84
Parameter Value
Meaning
47
e
e – e = 0 selected numbers from Group 1/Group 2 mode. Door phone will switch automatically from Group 1 to Group
2 numbering plan when numbers of rings set in parameter 84 is riched
e = 1 selected numbers from Day/Night mode. Door phone will wait for a manual switching from Day to Night
mode numbering plan or when the same buttons is redialled.
List of related parameters: 1 2 8# 84
ATTENTION !! This parameter setting will sharply influence the dialing.
Parameter Value
Meaning
48
c
c – c = 0 No keypad connected to the Main module
c = 1 keypad UCKN connected on the first position
c = 2 keypad UCKN connected on the second position
c = 3 Keypad UCKN connected on third position
ATTENTION !! This parameter setting will sharply influence whole Doorphone function.
List of related parameters: 1 2 32 33 34 47 49 53 8# 84
Parameter Value
Meaning
49
o
All rights are reserved to Linkcom
Main
Extend conversation
Main
Hanging from phone
Main
Password for Remote
Main
Main
Mode of dial numbers
Group 1 / Group 2
Day / Night
Main
Keypad position
Main
Keypad Mode
LINK DOOR PHONE
Exam.1 Exam.2
*
*
*
Exam.1 Exam.2
155 266 155 244 155 244
Exam.1 Exam.2
0000
0000
0000
Exam.1 Exam.2
11
11
11
10
10
10
Exam.1 Exam.2
1
1
0
Exam.1 Exam.2
0
0
1
Exam.1 Exam.2
0
1
0
classe
classement
LinkDoor
DR
– Installation and Operating Instructions
Number
date
15/04/05
001
page
16/31
