By password choice some rules have to be observed:
Select passwords in way not to find its combination out from wear of certain direct call buttons.
Select the first password from frequentless button for direct dialing (-extends choice time)(-not valid for
keypad).
Pay attention to password choice numbers when one password includes other one, e.g. Relay 1 has 1234 and
Relay 2 has 12345. Then after pressing button 4 the only Relay 1 is activated, but password choice 234 for
Relay 2 can activate both Relays after pressing digit 5.
Note: The Relay over to Day/Night mode remains set in Doorphone even after line disconnection.
List of related parameters: 31 35 36 37 38 45 46 47 48 49 53 8# 83
Parameter Value Meaning
Command aa from phone
35
r aa
after r Relay activation
r
– Relay number [1-2]
aa – Prefix dialled from phone to activate Relay [2 digits].
The same prefix can be set for both Relays, then they are activated at the same time.
It is recommanded to set the same prefix for Doorphone hanging up (parameter 43) aa=bb.
List of related parameters: 31 36 37 38 43 8# 83
Parameter Value
Meaning
36
r ss
r
– Relay number [1-2]
ss – duration of Relay activation [2 digits 01-99] in second
List of related parameters: 31 32 33 34 35 37 38 8# 83
Parameter Value
Meaning
37
r p
r
– Relay number [1-2]
p – Parameter, if p=1 allowed or p=0 prohibited to control the Relay during incoming call.
Allow the control of Relays when the call is made from PBX to Door Phone
List of related parameters: 31 35 8# 83
Parameter Value
Meaning
38
xx
xx – time between the activation of Relay 1 and starting the activation of Relay 2
Mode 5 have to be selected for Relay 2 in RELAYS Parameter m=5 mode setting [2 digits 01-99]
List of related parameters: 31 32 33 34 35 36 37 8# 83
2.5 Main Parameters
Parameter Value
Meaning
41
v
v – Dialing mode
v = 0 Tone (DTMF) mode,
v = 1 Pulse (DC) mode
List of related parameters: 1 2 8# 84
All rights are reserved to Linkcom
Relay time activation
Allow communication to
Doorphone
Stend by time before
activating Relay 2 from
Realy 1[s]
Dialling mode
Tone or Pulse
Main
Exam.1
Exam.2
155 266 155 266 155 266
Main
Exam.1 Exam.2
105 205 102 202 105 205
Main
Exam.1 Exam.2
11 21
11 21
11 21
Main
Exam.1 Exam.2
10
10
15
Main
Exam.1 Exam.2
0
0
0
classe
classement
LinkDoor
DR
Number
date
15/04/05
001
page
15/31
