5.3 LINK BOX/Gap Programming
You can enter the programming mode 20 sec – 10min after power supply ON by **9 choice (to dial/busy tones)
namely after LINK BOX/Gap power supply ON. If you had entered a new PIN in previous programming (par.2) so now
you must enter a correct PIN for entry to programming (following main reset (par. 90) the PIN should not be entered).
The special dialing tone is heard in programming mode. The entry and correct PIN are confirmed by confirmation tone,
the false PIN by error tone.
Param.
Value
**9
[xxxx]
entry to programming, xxxx=PIN, if entered
0
#
log off – stored DECT parameters will be deleted
1
xxxxxxxx # entry code to base station (4-8 numbers)
PIN change - xxxx is old, yyyy is new, 0000 is firm
2
xxxx yyyy #
one
distance – number load is multiple of 130m (300m =
3
0# - 79#
3)
choice mode - 0 sends / 1 suppresses DTMF choice
40
0# / 1#
transmission from base station (0 is pract. doubled
choice)
41
0# / 1#
operational setting - 0 is phone / 1 is FAX
70
0# / 1# / 2# call limitation - 0 not limited, 1 incoming, 2 outcoming
71
0# / 1# / 2# type of call - 0 both, 1 internal, 2 external call
Flash length – xxx times 10ms (100ms = 010)
72
xxx #
firm.=210ms
90
#
reset and company setting (bold), presets all
reset and company setting (bold), log in parameters
91
#
will be kept
autoreset 0-inactive / 1-active (every 24 hrs will end
92
0# / 1#
all transmissions and recall to base station)
Settings for use with Doorphone: (90#), 401#, 410#, 700#, 710#
Internal call will be executed by **s, where s is 0-9 i.e. number of internal station, station 9 may be called 10min after
power supply ON, up to this moment it is entry to programming.
Note: The Relaying of call/internal query can be made by "Flash" and **s choices. The call will be Relayed over by
hanging up. The "Flash" function will turn back to previous call.
5.4 Log on to Base Station
The log in might be done automatically in this way that we hold the button for searching on base station (min 3sec)
and then we will connect the power supply to LINK BOX/Gap. This will automatically log on to base station within 1 min
and if not made it is recommended to make the company reset (90#) and repeat logging on. Setting of parameters
401#, 410#, 700#, 710# is required.
Be sure about parameter 40, which is being set after company reset thus that the choice is transmissed not only by
Doorphone, but also the base station so that the choice is executed twice!!
All rights are reserved to Linkcom
Meaning
classe
classement
LinkDoor
DR
LINK DOOR PHONE
– Installation and Operating Instructions
Number
date
15/04/05
001
page
30/31
