Description of Parameters

2.3 Direct Dialing – Memories
Parameter Value
Meaning
No. nn under button tt
1
tt nn...
Day/Groupe 1 mode
tt – Button number (memory), always set in two-digit from [01-64]
nn – telephone number max 16 digits,
The numbers stored in parameter 1 are the number associated to Groupe 1 and Day mode
Parameter Value
Meaning
No. nn under button tt
2
tt nn...
Night/Groupe 2 mode
tt
– Button number (memory), always set in two-digit from [01-64]
nn – telephone number max 16 digits,
The numbers stored in parameter 2 are the number associated to Groupe 2 and Night mode
Note : Data will be saved in the Door Phone even when PSTN line is disconnected
Parameter list in relation with this feature: 41 45 46 47 48 49 57 58 59 50 81 82
2.4 Relays
Parameter Value
Meaning
31
r m
r
– Relay number [1-2]
m – Relay mode [for r=1 1-4 , for r=2 1-5]
m=1 Relay mode – Relay will be activated for ss period (used for electrical locks, gate opening etc.)
m=2 camera mode – Relay will be activated on Door Phone lifting up and desactivating by hanging up.
m=3 lighting mode – Relay will be activated on Door Phone lifting up and stay activated even for ss period after
Doorphone hanging up (the line is engaged for this period).
m=4 Relay mode – Relay will be activated when Door Phone button is being presseed and desactivate after ss period
(used for e.g. external bell or horn connections).
m=5 Temporised activation mode – This mode is available only for Relay N°2 .
Relay N° 2 will be activated only after a setting period begening after the activation of Relay N° 1
List of related parameters: 32 33 34 35 36 37 38 8# 83 r
Parameter Value
Meaning
32
r hhhhhh
33
r hhhhhh
34
r hhhhhh
r
– Relay number [1-2]
hhhhhh – password for relay activation when dialed from Direct Call buttons (C4N and M4N) or keypad
[2 to 6 digits]
Total of 6 passwords can be programmed; they are controlled by Day/Night mode.
the combination is entered either by Doorphone Direct call buttons (first 10 buttons) or from attached keypad
(after pressing of key symbol).
All rights are reserved to Linkcom
Main
Max 16 Digits
-
Main
Max 16 Digits
-
Main
Relaying mode
11 21
Main
Password in mode
DAY + NIGHT
Password in mode
DAY
Password in mode
NIGHT
Exam.1
Exam.2
-
-
Exam.1
Exam.2
-
-
Exam.1
Exam.2
11 22
11 25
Exam.1
Exam.2
1 121
1 4561
-
2 122
2 4562
-
-
-
-
-
-
classe
classement
LinkDoor
DR
Number
date
15/04/05
001
page
14/31
