Parameter Value Meaning
56 h
h – After finishing the dialing, number of KVT (ringing tones) is being counted. If the number exceeds h value, it will
hang up [range 04-99]. The dialing is repeated in case Group 1/Group 2 has been set.
List of related parameters: 47 8# 85
Parameter Value Meaning
57 t
58 m
59 f
50 p
t – DTMF tone duration is determined by the formula:
entered number + 5) x 10 = tone duration [ms]
m – Gap duration among DTMF tones is determined by the formula:
entered number + 5) x 10 = gap duration [ms]
f – Flash duration is determined by the formula:
entered number x 100 = Flash duration [ms]
p – Pause duration is determined by the formula:
entered number x 100 = pause duration [ms]
P – Time is simultaneously the duration of interdigit gap at pulse dialing.
List of related parameters: 1 2 41 8# 85
2.7 Presetting and Deleting
Parameter Value Meaning
8# #
8# 1 Setting per exam. 1
8# 2 Setting per exam. 2
This setting does not influence 1 and 2 (numbers stored in memory)
Parameter Value Meaning
81
82
83
84
85
All rights are reserved to Linkcom
Number of ring until
allowed
DTMF Tone Duration
DTMF Space Duration
Flash Duration
Pause Duration /
internumber spaces dial
[range 1-0 i.e. 60-150ms]
[range 1-0 i.e. 60-150ms]
[range 1-6 i.e. 100-600ms]
[range 5-0 i.e. 500-1000ms]
Main
Main setting executes
deletes all numbers in
Group 1/Day mode
deletes all numbers in
Group 2 /Night mode
Main setting only
for parameters 3x
Main setting only
for parameters 4x
Main setting only
for parameters 5x
LINK DOOR PHONE
Main Exam.1 Exam.2
12 12 12
Main Exam.1 Exam.2
5 5 5
(100ms) (100ms) (100ms)
5 5 5
(100ms) (100ms) (100ms)
1 1 1
(100ms) (100ms) (100ms)
8 8 8
(800ms) (800ms) (800ms)
Exam.1 Exam.2
executes
executes
Main Exam.1 Exam.2
only 3..
only 4..
only 5..
classe
classement
LinkDoor
DR
– Installation and Operating Instructions
