Main Description
1.1 Features:
The LINK DOOR PHONE is a modular system which from a Main module (UCxN) allow to connect IP or IP
WiFi camera, KEYPAD ( UCKN) and a maximum of 16 x 4 direct call button modul C4N (MASTER) or M4N
(SLAVE ) total 64 buttons to manage up to 64 companies or service department by direct call
Voice communication is supplied by the telephone line ( PBX, PSTN line or analog GSM Gateway )
The link between the Door Phone and the PBX can be wireless by using our device LINK BOX/Gap
Mixt dialling available, TONE or PULSE
Two 16 digits numbers can be programmed in each memory table for direct call button of modul C4N (Master)
and M4N (Slave) (including (*, #, Flash and Pause)
The first number is associated to Group 1 / DAY mode
The second number is associated to Group 2 / Night mode
A total of 2 x 64 numbers are associated to the 64 direct call button
The numbers are associate to prefix 01 to 64 and can be dialled from the Keypad ( UCKN)
Programming the numbers of ring before automatic Relaying from Groupe 1 to Groupe 2
Manual Relaying from DAY to NIGHT or NIGHT to DAY mode, from a phone or automatic Relaying when
pressing again the button in case of no answering or busy line .
Extending the communication between PBX and Door Phone by dialing from phone * ou # when hearing the
end of conversation signal.
Possibility to manage two Relays independently and by temporization for the Relay N°2.
The Relaying of the 2 relays is done by dialing from the phone a prefix of 2 digits. Relay N°2 can be Relayed,
based on temporization setting starting after the activation of first relay.
A six digits password can be dialed from Keypad or by a combination on the first 10 Direct call Button (When
Keypad is not available)
Deadline parameters setting between 2 pressures on Direct call Button for password seizure.
Keypad dialling mode can be done either by:
-Dialling the full PSTN number or PBX extension number
-By using prefix memory table of the DoorPhone (01-64)
Deadline parameter between 2 calls can be programmed
Flash and Pause Setting
Choice between the 3 default setting tables
PC setting in local mode and DTMF in Remote mode
The Main module (UCxN) is Integrating heating of printed circuit
Permanent lighting through visiting cards
Earthing outlet for better protection against static electricity
Powering the whole module in 12V AC or DC without polarity.
