2 Programming the Doorphone

2.1 Programming through Phone (Remot mode)
2 Ways
1. To enter the programming mode, call the Door Phone and when hearing the tone dial # 9 followed by the
password 0000 by default ( See parameter 44 )
2. by "SERVICE" jumper ( See Main module connection chapter) call the Door Phone you hear directly the
programming mode tone allowing you entering in programming mode directly.
2.2 Programming from PC –Nset software
To Doorphone's setup by means of personal computer (PC) the special KAB cable to serial port and Nset program
should be available and the Doorphone has to be connected to phone line.
Procedure:
1) Connect the UCxN to the line (PBX, PSTN or GSM Gateway)
2) Line the Main module of the Doorphone with PC by KAB cable (Option) if PC serial port is absent, the USB-
COM reduction is to be used. The Doorphone will answer and LED light on the front panel will light.
3) Run the Nset program
4) Program the Door Phone through Nset software
5) Transfer from PC to Door Phone Main module programmed sequences
Transfer Status is displayed on your computer
If connection is lost, it is necessary to disconnect and connect back KAB cable
