DECT – LINK BOX/Gap
5.1 LINK BOX/Gap Description
This module is a separate box allowing the connection of an analog
telecommunication device to wireless system DECT – GAP . LINK
BOX/Gap is suitable for Doorphone connection, because it is not
necessary to place the conductors from house to the gate and to address
to base station is enough sufficient. All Doorphone features are reserved.
LINK BOX/Gap must be energized to power supply and the Doorphone s
to outputs of analog line (indicated on figure) – both outputs of analogue
line are parallel. The LINK BOX/Gap 300 contains an internal antenna
allowing the connection of 300 m direct visibility and 50 m in building. The
LINK BOX/Gap 5000 can be fitted with an external antenna increasing the
range to 6 km.
5.2 LINK BOX/Gap Signaling
LED indication
| Time interval is 8sec |
Relayed off
Tones
All rights are reserved to Linkcom
- no power supply
- ready to use and addressed to base station
- incoming searching call
- connection
- programming mode
- searching for base station
- base station found
- base station not found
- dial tone
- special dial tone (modulated)
- busy tone
- confirmation tone
- error tone
classe
classement
LinkDoor
DR
Number
date
15/04/05
001
page
29/31
