Wifi / IP Camera
Set up the wireless connection – Windows
Before the doorphone with Wi-Fi camera can connect to an encrypted wireless network, the wireless settings in the
camera must be configured and an IP address must be set. This is done by connecting the camera to a computer with
the help of the supplied USB cable. Follow the instructions below.
1. Connect the power adapter to the camera. Press the power cable into the cable clip on the
rear panel. This will prevent accidental cable disconnection.
2. Connect the USB cable to your computer and then to the camera.
3. Open My Computer and the camera
should be displayed as a new drive
4. Click on the drive for the camera to see
the files contained in the camera.
5. Click on the file setup.exe. This starts the
AXIS Setup Tool, which lets you configure
the wireless settings. See the online help in the setup tool for more
information. Note that you should first configure your
wireless access point and then duplicate
those settings in the camera settings.
6. Specify the type of IP address to use. Seethe online help for
more information.
For easiest access to the camera – we recommended to use static
IP address.
IP address have to be from the same IP range as Wifi network.
7. Click OK, close the AXIS Setup Tool and disconnect the USB
cable.
8. Wait at least 10 seconds for the settings to take effect and then
restart the camera ( disconnect a power supply )
