Quick Start Guide
1

Video Features

This computer features an NVIDIA Scalable Link Interface (SLI) that improves graphic quality and perfor-
mance by combining dual NVIDIA GPUs in a single system to allow the two graphics cards to run in parallel.
You can switch display devices, and configure display options, from the Display Properties control panel in
Windows as long as the appropriate video driver is installed.
To access Display Properties in Windows:
1. Click Start, point to Settings and click Control Panel (or just click Control Panel).
2. Double-click Display (icon) - In the Appearances and Themes category.
3. Click Settings (tab) in the Display Properties dialog box.
(You can also access Display Properties by right-clicking the desktop and scrolling down and clicking
Properties. Click Settings and adjust as above.)
4. Move the slider to the preferred setting in Screen area/resolution
5. Click the arrow, and scroll to the preferred setting In Colors/Color quality
6. Click Advanced (button)
7. Click GeForce Go ... (tab).
8. Clicking the tabs or Additional Properties allows you to make any video adjustments you require.
Display Devices & Options
Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or
TV as your display device (Note: SLI Multi-GPU supports only single display mode). A VGA monitor/Flat
Panel Display connects to the DVI-Out port, a TV to the S-Video-Out jack. See
a summary of the display modes available, and see
detailed video information.
1 - 14 Video Features
(Figure 1 - 9 on page 1 -
3
"NVIDIA Video Driver Controls" on page B - 1
(Figure 1 - 9 on page 1 -
1
(Figure 1 - 9 on page 1 -
2
15) to bring up the Advanced properties tabs.
Table 1 - 5, on page 1 - 15
15).
15).
for
for more
