3. Remove the bay cover
4. Gently pull the two release latches (
the direction indicated by the arrows in
.
14
14
)
& on the sides of the memory socket in
15 16
Figure 6 -
15
5.
16
Upgrading the System Memory (RAM) 6 - 7
Upgrading The Computer
Figure 6 - 6
Bay Cover Removal
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the cleanest
hands have oils which
can attract particles, and
degrade the module's
performance.
Figure 6 - 5
RAM Module
Release
6
