7.2

Testing the IP Connection

Make sure that the print server will be recognized in the network by
the AS/400/iSeries.
Proceed as follows:
1. Enter the following command into an OS/400 command line:
PING' <IP address or host name of the print server>'
The result of the connection will be displayed.
The IP address or the host name must be put in single quotation
marks.
If a connection cannot be achieved, check the network cabling and
the IP connection of the print server from a PC. Make sure that the
required TCP servers are started on the AS/400/iSeries.
7.3

Creating the Device Description

A remote device printer may be created using the CRTDEVPRT
command. Depending on the release version of the OS/400, the
keywords and parameters for the creation of a device description
may differ slightly from the following description (V5R1).
Before creating a device description, make sure that there is no
other device with the same name.
Proceed as follows:
1. Log in using a user profile.
This user profile has *IOSYSCFG special authority.
(alternatively QSECOFR).
2. Enter the following command:
CRTDEVPRT
3. Press F4. The command prompt is displayed.
4. Press F9. The following dialog appears:
AS/400 - Printing via a Device Description
57
