SEH Print Server Installation Manual page 24

Installation with HP
VUE
Print Server Installation Manual
6. Enter an arbitrary printer name into the Printer Name box:
Example: my_printer
7. Enter the host name of the print server into the Remote System
Name box:
Example: IC0001FF
8. Enter a logical printer (lp1 - lp8) into the Remote Printer Name
box:
Example: lp1
With print servers with several physical printer ports, the logical printer is used to
address the port. For more information, please read the section 'Logical Printers'
in the user manual.
9. Select the Remote Printer is on a BSD System box:
Example: [ ] Remote Printer is on a BSD System.
10. Click OK to confirm.
Proceed as follows:
1. Start HP VUE.
2. Start the Printer/Plotter Manager.
3. Select Printers/Plotters from the List menu.
4. Select Add Remote Printer/Plotter... on the Actions menu.
5. Enter an arbitrary printer name into the Printer Name box:
Example: my_printer
6. Enter the host name of the print server into the Remote System
Name box:
Example: IC0001FF
7. Enter a logical printer (lp1 - lp8) into the Remote Printer Name
box:
Example: lp1
With print servers with several physical printer ports, the logical printer is used to
address the port. For more information, please read the section 'Logical Printers'
in the user manual.
8. Select the Remote Printer is on a BSD System box:
Example: [ ] Remote Printer is on a BSD System.
The print server status can be viewed using the Printer/Plotter
Manager or the 'lpstat' shell program.
Printing via the LPD Protocol
24
