85DIV / 85DIV-L
* UART Mode Select The second serial port on your system may offer
a variety of infrared port modes. Click here for a
description of various modes. (Click your
browser 's Back button, or your right mouse
button, to return to this page.)
The choices: Standard; HPSIR; ASKIR
* UR2 Duplex Mode This item allows you to select the IR half / full
duplex function.
The choices: Half; Full
* Onboard Parallel Port This item allows you to determine onboard parallel
port controller I/O address setting.
The choices: 378H/IRQ7; 278H/IRQ5; 3BC/IRQ7;
Disabled
* Parallel Port Mode Select an operating mode for the on-board parallel
(printer) port. Select Normal, Compatible, or SPP
unless you are certain your hardware and software
both support one of the other available modes.
Choices: SPP; EPP; ECP; ECP+EPP
* ECP Mode Use DMA Select a DMA channel for the port when you choose
ECP or ECP+EPP mode for the Parallel Port Mode.
Choices: 1; 3
* Game Port Address This item allows you to select the Game Port
Address.
The choices: Disabled, 201, 209
* MIDI Port Address Select a DMA channel for the parallel port for use
during ECP mode.
The choices: Disabled, 330, 300
* MIDI Port IRQ This item allows you to select the MIDI Port IRQ.
The choices: 5, 10
72
