85DIV / 85DIV-L
1-2 Mainboard Specification Table
Model/Series
Memory
Controller Hub
I/O
Controller Hub
CPU Socket
Memory
I/O Chip
Audio
Onboard IDE
AGP Interface
I/O Connectors
PCI slot
LAN Controller
BIOS writing
Protection
Hardware
Monitoring
85DIV / 85DIV-L
North Bridge VIA P4x266 A
South Bridge VIA VT8233A
Socket PGA478B for Intel Pentium 4 478-pin package CPU
Supporting 2GB unbuffered
DDR SDRAMs with 2 DDR DIMM Slots
AC'97 Audio Codec
2 x UATA 33/66/100/133 IDE ports
AGP 4X / 2X Mode
4 x USB ports, 1 x FDD port, 2 x COM ports,
1 x LPT port, 1 IrDA, 1 PS/2 Mouse, 1 PS/2 K/B
3 PCI Master Slots
(for 85DIV-L only) RTL8139C on board, supporting 1 Rj45
14
ITE IT8705F
Built-in
Built-in
