MAXI 6560 User's Guide
One special feature of the MAXI 6560 is the Front I/O, Rear I/O options. Now
the connectors and cables all go from the rear side. This makes a clean operation
environment and significantly shortens the MTTR. The MAXI 6560 also
supports the PICMG Hot Swap spec. (PICMG 2.1). So the product is really
suitable for the mission critical applications. All these I/O's are arranged
through J4 & J5. As to J1 & J2, they are reserved for the primary cPCI channel,
supporting up to 7 cPCI slots.
The notebook type floppy connector and IDE connector are reserved. The watch
dog timer is on board. The Flash ROM BIOS is also standard for easier BIOS
update. The IDE supports mode 4 PIO, mode 2 DMA master and ultra DMA/33.
The MAXI 6560 will be available with four models, depending on the memory size
mounted on board and Front/Rear I/O's as the following table shows:
Feature
Model
MAXI 6560F/64
MAXI 6560F/128
MAXI 6560R/64
MAXI 6560R/128
Specifications
Common Memory
Features Size
YES 64MB
YES 128MB
YES 64MB
YES 128MB
I/O
Front
Front
Rear
Rear
1-2
