MAXI 6560 Series User's Guide
PM Timers
The following four modes are Green PC power saving functions which are only user
configurable when User Defined Power Management has been selected. See above
for available selections.

Doze Mode

When enabled and after the set time of system inactivity, the CPU clock will run at
slower speed while all other devices still operate at full speed.

Standby Mode

When enabled and after the set time of system inactivity, the fixed disk drive and the
video would be shut off while all other devices still operate at full speed.
Standby Mode
System will never enter STANDBY mode
1. Disable
Defines the continuous idle time before the system entering
2. 1 Min
STANDBY mode.
2 Min
4 Min
6 Min If any item defined in (J) is enabled & active, STANDBY timer
will be reloaded
8 Min
10 Min
20 Min
30 Min
40 Min
1 Hr

Suspend Mode

When enabled and after the set time of system inactivity, all devices except the CPU
will be shut off.

HDD Power Down

When enabled and after the set time of system inactivity, the hard disk drive will be
powered down while all other devices remain active.
Throttle Duty Cycle
When the system enters Doze mode, the CPU clock runs only part of the time.
You may select the percent of time that the clock runs.
The Choice: 12.5%, 25.0%, 37.5%, 50.0%, 62.5%
BIOS Setup
, 75.0%
(Default)
4- 19
