MAXI 6560 Series User's Guide
The Onboard UART 1 and UART 2 could be set as below:
Auto
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Different port requires different address to avoid conflicts.
On board UART 2 Mode
This item allows you to determine which Infra Red (IR) function of onboard I/O chip.
The Choice: Standard (Default), ASKIR, HPSIR.

Onboard Parallel Port

Select a logical LPT port name and matching address for the physical parallel
(printer) port. The choice: 378H/IRQ7

Parallel Port Mode

Select an operating mode for the onboard parallel port. Select Compatible or Extended
unless you are certain both your hardware and software support EPP or ECP mode.
The choice: SPP, ECP+EPP1.7, EPP1.7+SPP, EPP1.9+SPP, ECP, ECP+EPP1.9, and Normal.

ECP Mode Use DMA

When the mode selected for the onboard parallel port is ECP, the DMA channel
selected can be Channel 1 or Channel 3.

EPP Mode Select

When the mode selected for the onboard parallel port is EPP, two EPP version
options are available: EPP1.7 or EPP1.9

Onboard Serial Port 3

This allows Onboard Serial Port 3 to set up disabled or 3F8H, 2F8H, 3E8H, 2E8H
Serial Port 3 Use IRQ
This allows Serial Port 3 to use IRQ 10, 11, 9, 5
BIOS Setup
Default
, 278H/IRQ5, 3BCH/IRQ7, Disabled.
(Default)
4- 25
