MAXI 6560 Series User's Guide
Disabled
Min. Power
Saving
Max. Power
Saving
(Default)
User Define
PM Control by APM
When enabled, an Advanced Power Management device will be activated to
enhance the Max. Power Saving mode and stop the CPU internal clock.
If the Max. Power Saving is not enabled, this will be preset to No.

Video Off Method

This determines the manner in which the monitor is blanked.
V/H SYNC+Blank
(Default)
Blank Screen
DPMS
Video Off After
When enabled, this feature allows the VGA adapter to operate in a power saving
mode.
N/A Monitor will remain on during power saving modes.
Suspend Monitor blanked when the systems enters the Suspend mode.
Standby Monitor blanked when the system enters Standby mode.
Doze Monitor blanked when the system enters any power saving
mode.

MODEM Use IRQ

Name the interrupt request (IRQ) line assigned to the modem (if any) on your
system. Activity of the selected IRQ always awakens the system.
The choices: NA, 3
BIOS Setup
No power management. Disable all four modes
Minimu m power management. Doze Mode = 1 hr. Standby
Mode = 1 hr., Suspend Mode = 1 hr., and HDD Power Down
= 15 min.
Maximum power management -- ONLY AVAILABLE FOR
SL CPU'S . Doze Mode = 1 min., Standby Mode = 1 min.,
Suspend Mode = 1 min., and HDD Power Down = 1 min.
Allows you to set each mode individually. When not
disabled, each of the ranges are from 1 min. to 1 hr. except
for HDD Power Down which ranges from 1 min. to 15 min.
and disable.
This selection will cause the system to turn off the vertical
and horizontal synchronization ports and write blanks to
the video buffer.
This option only writes blanks to the video buffe r.
Initial display power management signaling.
, 4, 5, 7, 9, 10, 11
(Default)
4- 18
