MAXI 6560 Series User's Guide
Floppy
FD_MTR0(1)#, FD_DS0(1)#, FD_DRV0(1)#, FD_TRK0#,
FD_STEP#, FD_DIR#, FD_RDAT#, FD_WRPT#, FD_WGATE#,
FD_INDX#, FD_DCHG#, FD_WDATA#
IR
IR_TX, IR_RX
LAN
RJ1, RJ2, RJ3, RJ4, RJ5, RJ6, RJ7, RJ8
SMBus
SMBCLK, SMBDATA
Other
SCSI_LED#, PWRLED#, LAN_ACTIVE#, LAN_LINK#,
LAN_SPD#, RST_BUT#, SPEAKER#
Switches and Connectors
2-10
