MAXI 6560 User's Guide
l
CPCI connector Definition
st
J1J2 for 1 PCI Bus
J4J5 for Rear I/O
IDE x 2
FDC x 1
100 Base T
Ultra 2 SCSI
4S1P
KBD/Mouse
VGA
Panel Connector (LVD)
l
Dimensions
Dimensions: 233.35mm(D) x 160mm(W)
l
Power requirements
+3.3V: 12A (Max.)
+5V: 6A(Max)
l
Environments
Operating temperatures: 0°C to 60°C
Storage temperatures: -20°C to 80°C
Relative humidity: 10% to 90% (Non-condensing)
Specifications
1-6
