MAXI 6560 Series User's Guide
Memory Hole At 15M-16M.
In order to improve performance, certain space in memory can be reserved for ISA
cards.. This memory must be mapped into the memory space below 16 MB.
Enabled
Disabled
(Default)
Passive Release
When Enabled, CPU to PCI bus accesses are allowed druing passive release.
Othersiwe, the arbiter only accepts another PCI master access to local DRAM. The
Choice: Enabled, Disabled.
Delay Transaction
The chipset has an embeded 32-bit posted write buffer to support delay
transactions cycles.. Select Enabled to support compliance with PCI specification
version 2.1
AGP Aperture Size (MB)
Select the size of the Accelerated Graphics Port (AGP) aperture. The aperture is a
portion of the PCI memory address range dedicated for graphics memory address
space. Host cycles that hit the aperture range are forwarded to the AGP without any
translation. See
The choice: 4, 8, 16, 32, 64, 128, 256

CPU Warning Temperature

When the temperature is over the CPU warning temperature, then the warning signal
will come out.

Current CPU Temperature

This field displays the current CPU of system temperature.
Current CPU FAN1/2 Speed
These fields display the current speed of up to two CPU fans.
Current Voltage
These fields display the current voltge of up to four voltage.
BIOS Setup
Memory hole supported.
Memory hole not supported
www.agpforum.org for AGP information.
4- 16
