MAXI 6560 Series User's Guide
38 LVDM9 LVDP0
39 LVDP4 LVDM0
40 LVDM4 VCC3
41 VCC3 GND
42 GND BHSYNC
43 BVSYNC BLUE
44 ENABKL +12V
45 ENAVDD VCC3
46 LCD_TX0+ LCD_TX1-
47 LCD_TX0- LCD_TX1+
PIN Definition Group
VGA BHSYNC, BVSYNC, GREEN, RED, BLUE, DDCCLK, DDCDAT
Keyboard KB_DATA, KB_CLK
PS/2 Mouse MS_CLK, MS_DATA
LCD LCD_TX0+(-), LCD_TX1+(-), LCD_TX2+(- ), LCD_TX3+(-),
LCD_CLK0+(-), ENAVDD, ENKBAL
Ultra II SCSI LVDM0-15, LVDP0-15, LVREQM(P), LVIOM(P), LVCDM(P),
LVSELM(P), LVMSGM(P), LVRSTM(P), LVACKM(P), LVBSTM(P),
LVATNM(P), LVDPLM(P), LVDPHM(P), DIFFSENSE
Parallel Port L1_D0-7, L1_SLCT, L1_ACK#, L1_PE, L1_BUSY, L1_SLIN#,
L1_INIT#, L1_ERROR#, L1_STROB#, L1_AFEED#
Serial Port 1. With RS422/485 Function:
C1(3)_RTS, C1(3)_CTS, C1(3)_DTR, C1(3)_DSR, C1(3)_RI,
C1(3)_DCD, C1(3)_RXD, C1(3)_TXD.
2. Only RS232 Function:
RTS2(4)#, CTS2(4)#, DTR2(4)#, DSR2(4)#, RI2(4)#, DCD2(4)#,
RXD2(4), TXD2(4)
USB USB1+, USB1-, USB2+, USB2-
IDE HD_D0-D15, HD_CS1(3)A#, HD_IOW#, HD_IOR#, HD_ACK0#,
HD_DRQ0, HD_RDY, HD_IRQ14, HD_RST#, HD_A0-3
Switches and Connectors
LVDM14 LVDP15
LVDP14 LVDM15
LVDM1 LVDP11
LVDPI LVDM11
VCC3 DDCCLK
DDCDAT RED
GREED MS_CLK
GND MS_DATA
LCD_TX2+ LCD_TX3+
LCD_TX2- LCD_TX3-
LVDM8 GND
LVDP8 GND
LVDM3 GND
LVDP3 GND
VCC3 GND
GND GND
KB_CLK GND
KB_DATA GND
LCD_CLK0+ GND
LCD_CLK0- GND
2-9
