Table A.19: CN28: Mini PCIE lock
Part Number
Footprint
Description
Pin
Table A.20: CN29: Mini PCIE slot
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
UTC-515 User Manual
1654002539
FOX_AS0B226-S68K7F_HOLDER
MINI PCI Express LATCH 52P 90D SMD 6.8mm
Pin Name
1654002538
FOX_AS0B226-S68K7F
MINI PCI express 52P 90D SMD H=6.8mm
Pin Name
WAKE#
+3.3V or +3.3VSB
NC
GND
NC
+1.5V
CLKREQ#
NC
GND
NC
REFCLK-
NC
REFCLK+
NC
GND
