Table A.10: CN18: LAN1
Part Number
1652002996
Footprint
RJ45_14P_RTA-195AAK1A
Description
Phone Jack RJ45 14P 90D(M) DIP RTA-195AAK1A
Pin
Pin Name
Table A.11: CN19: LAN2
Part Number
1652002996
Footprint
RJ45_14P_RTA-195AAK1A
Description
Phone Jack RJ45 14P 90D(M) DIP RTA-195AAK1A
Pin
Pin Name
Table A.12: CN20: Power Switch (Low Active)
Part Number
1655302020
Footprint
WF_2P_79_BOX_R1_D
Description
WAFER BOX 2P 180D(M) 2.0mm W/Lock
Pin
Pin Name
1
PSIN
2
GND
