Table A.16: CN25: External USB
Part Number
Footprint
Description
Pin
1
2
3
4
Table A.17: CN26: COM1
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
UTC-515 User Manual
1654904105
USB-V-4A
USB CON. 4P 90D(F) DIP A TYPE RoHS
Pin Name
+5V
D-
D+
GND
1654000056
DBCOM-VM5MS
D-SUB CON. 9P 90D(M)DIP 070241MR009S200ZU SUYIN
Pin Name
DCD#
RXD
TXD
DTR#
GND
DSR#
RTS#
CTS#
RI#
38
