A.1 PIN Assignments
Table A.1: CN1: Audio
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
Matching Cable: 1703100152
Table A.2: CN3: SATA
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
UTC-515 User Manual
1653205260
HD_5x2P_79_BOX
BOX HEADER SMD 5*2 180D (M) 2.0mm
Pin Name
LOUTR
LINR
GND
GND
LOUTL
LINL
GND
GND
MIC1R
MIC1L
1654002320
FOX_LD1107V-S33T5
Serial ATA 7P 1.27 90D(M) SMD LD1107V-S33T5
Pin Name
GND
TX+
TX-
GND
RX-
RX+
GND
30
