Table 4.5: J4: Clear COMS
Part Number
Footprint
Description
Setting
(1-2)*
(2-3)
Table 4.6: J5: PAN VOL SEL
Part Number
Footprint
Description
Setting
(1-2)*
(2-3)
UTC-515 User Manual
1653003101
HD_3x1P_79_D
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb
Function
Normal
Clear CMOS
1653003101
HD_3x1P_79_D
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb
Function
+5V
+3V
28
