■ Mounting

D Mounting location

Select a location which can support the weight of
the transceiver and does not interfere with driving.
We recommend the locations shown in the diagram
below.
NEVER place the main unit or remote controller where nor-
mal operation of the vehicle may be hindered or where it
could cause bodily injury.
D Mounting the controller or speaker
Check the installation angle; the display may not be easy
to read at some angles.
CONNECTION AND INSTALLATION
NEVER place the main unit or remote controller where air
bag deployment may be obstructed.
DO NOT place the main unit or remote controller where hot
or cold air blows directly onto it.
DO NOT place the main unit or remote controller in direct
sunlight.
These screws are shown as
mounting example only.
