Page 1: Service Manual
Service Manual ® Phaser Color Printer Warning The following servicing instructions are for use by qualified service personnel only. To avoid personal injury, do not perform any servicing other than that contained in operating instructions unless you are qualified to do so. This printing Dec 1996 070-9482-00...
Page 2: General Information
General Information This service manual contains information useful to verify operation, troubleshoot, repair, adjust, and maintain a Tektronix Phaser® 600 Color Printer. The ﬁrst half of this manual familiarizes you with the printer; it provides information on installing and verifying the printer and training printer customers as a part of the Option S0 printer installation procedure.
Page 3: Printer Overview
(TekColor 4.0 and VPI), HPGL-C and includes a TrueType renderer for downloaded TrueType fonts. The Phaser 600 Color Printer prints at an addressability of 300 dots per inch (dpi) and features 17 built-in fonts and 8 Mbytes of RAM, which can be upgraded to either 24 Mbytes or 40 Mbytes with the addition of one 16-Mbyte or one 32-Mbyte RAM SIMM.
Page 4: Solid Inks
Solid inks, sometimes called phase-change inks, are solid at room temperature and are liquid at the higher temperature used during printing. The inks solidify almost instantly after being jetted onto the printer’s media. Because Tektronix' proprietary solid inks bleed much less than ordinary liquid inks, they allow the printer to print brilliant colors on plain paper.
Page 5: Print Engine Assemblies
General Information Print engine assemblies Top cover Ink loader Drum motor assembly Clamp (bail) rollers Back tension blade Maintenance station Printhead Roll holder Stripper fingers Fuser pump 9482-02 Figure 1-2 Internal features of the print engine Phaser 600 Color Printer...
Page 6 General Information Ink loader Left junction board board Top cover interconnect board Carriage board Power supply (in electronics bay) Engine control board Image processor (in electronics bay) board Heater (in card cage) interconnect board Right junction board 9482-03 Figure 1-3 Circuit boards of the print engine Service Manual...
Page 7 Left sensor fuser- closed sensor Exit sensor Right fuser- closed sensor Right paper- edge sensor Left paper- (on printhead) edge sensor Waste bin (on printhead) sensor 9482-05 Figure 1-4 Sensors and switches on the print engine Phaser 600 Color Printer...
Page 8 General Information Printhead Clamp-close cover motor solenoids X-axis Ink-load motor motors (4) Y-axis motor Fuser motor Head-to- Paper-exit media motor motor Clamp-rotate solenoids Head maintenance cam gear motor 9482-06 Figure 1-5 Motors and solenoids on the print engine Service Manual...
Page 9 Sensors in the printer provide information to the engine control board to determine the state of the printer. The printer monitors the positions of some of the movable assemblies, such as the printhead, as well as the temperature of the printhead and fuser bar. Phaser 600 Color Printer...
Page 10: The Image Processor Board
General Information The image processor board Prominent on the image processor board is the ROM code SIMM and the RAM SIMM plug-in modules. Network connection is provided through the plug-in network card. The printer stores unique printer status and PostScript values in its NVRAM module.
Page 11: Front Panel
Pressing and holding Button 2, as you turn on the printer, executes extended diagnostics. The Chapter 9 topic, “Resetting NVRAM” on page 9-34 explains how to use the front panel buttons to reset the NVRAM to its factory default values. 9482-09 Figure 1-8 Printer front panel 1-10 Phaser 600 Color Printer...
Page 12: Rear Panel
General Information Rear panel Connectors The rear panel of the printer features the host interface connectors to the printer; it includes the following connectors: Standard parallel (high-density connector) SCSI high-density connector (font hard disk drive or CD-ROM only) 5-pin service port (for using PC-based diagnostics) With the addition of a PhaserShare network card, the printer can feature either of these connector combinations: RS-232 serial and LocalTalk connectors...
Page 13: Specifications
ﬂatness: contact with the surface. The printer should not be tilted more than 15 from horizontal for more than 1 minute while the printer is idle or the ink is hot (in liquid state). 1-12 Phaser 600 Color Printer...
Page 14 General Information Table 1-4 Functional speciﬁcations Characteristic Speciﬁcation Printing process Solid ink-jet onto plain paper. Color medium Cyan, magenta, yellow and black ink sticks, each shape-coded. The printer uses the subtractive color system to produce the colors red, green, and blue. Only black ink is used to create the color black.
Page 15 -78 VDC ± 2% (adjustable from -68 to -102 VDC RF emissions Both 115 and 220 VAC-conﬁgured instruments pass these standards: FCC Part 15 Class B EN55022 (CISPR 22) Class B VCCI (CISPR 22) Class B 1-14 Phaser 600 Color Printer...
Page 16 General Information Table 1-6 Environmental speciﬁcations Characteristic Speciﬁcation Temperature ° ° Operating 15 to 32 C (59 to 90 ° ° Storage and shipping -30 to 60 C (-22 to 140 Humidity Operating 10 to 80% relative humidity, non-condensing Non-operating 10 to 95% relative humidity, non-condensing Altitude °...
Page 17: Regulatory Specifications
General Information Regulatory speciﬁcations The Phaser 600 is in conformance with the following regulatory standards: FCC Part 15 Class B (for 115 VAC equipment) EN55022 (CISPR 22) Class B VCCI (CISPR 22) Class B The packaged product meets National Safe Transit Committee Test...
Page 18 Drivers This chapter discusses installing the printer and its drivers as a part of the S0 installation option. Tektronix Service Option S0 consists of three main functions detailed in this and the next two chapters of this manual: Chapter 2 “Installing the Printer and Drivers.” The ﬁrst portion of installation instructions, this chapter, consists of ﬁve basic processes:...
Page 19: Pre-Install Questions For Customers
Printer Name _____________________ Printer IP address__________________ Net Mask _________________________ Broadcast address _________________ Gateway__________________________ What software application packages will be used with the printer? (Some applications require special printing utility ﬁles.) _____________________________________________ Phaser 600 Color Printer...
Page 20 Customers must provide the particular interface cable or network adapter they need to use with the printer. Customers can purchase the following from the Tektronix Graphics Supplies Order Desk by calling 1-800-835-6100. Parallel cable, DB25-pin plug to Centronics 1284C 012-1468-00 Serial, 9-pin to 9-pin, 3 m (10 ft.), null modem...
Page 21 3.5-inch ﬂoppy disk drive, and a hard disk drive, 2 Mbytes RAM, 2 Mbytes of hard disk space DOS systems DOS 3.1 or later An application that supports color PostScript or HP-GL Windows systems Windows 3.1 Windows 95 OS/2 Windows for Workgroups 3.11 Windows NT and Daytona Phaser 600 Color Printer...
Page 22 1 Mbyte hard disk space for ﬁles Based on the results of the pre-install interview with the customer, you may wish to access the Tektronix Highly Automated Library (HAL) during business hours, at 1-800-835-6100 (ask to be transferred to HAL) for articles that may help with installing the printer into a customer's network.
Page 23: Installing The Printer
The printer and its accessories are shipped in a single box on a pallet. The following items are shipped with the printer: Unpacking Instructions Quick-Start Installation Instructions Phaser 600 Color Printer User Manual Phaser 600 CD-ROM and diskettes TekColor Care information (including the registration card) Phaser 600 Quick Reference Card...
Page 24: Removing The Packing Material
Installing the Printer and Drivers Removing the packing material Note Save all packing material in case moving or subsequent shipment is necessary. Follow the instruction on the exterior of the shipping box to remove the exterior packing material. Remove any adhesive tape that holds the printer’s doors shut. 9482-119 Figure 2-1 Removing the packing material Service Manual...
Page 25 Lift the ramps off the pallet and place them into the openings on the side of the pallet. 9482-120 Figure 2-2 Installing the ramps Insert one bolt into each ramp at the point where the ramp rests on the pallet. The bolts serve as pegs and are not tightened. Phaser 600 Color Printer...
Page 26 Installing the Printer and Drivers Raise the levelers at each end of the printer. There is one leveler next to each wheel. Remove the block of wood from the left side of the printer and place it under the ramps for support. 3-2628-07 Figure 2-3 Remove the wooden block Removing the printer from the shipping pallet...
Page 27 Remove the bolts from the ramp. Slide the ramps onto the pallet and secure with the bolts. Store or discard the pallet. Roll the printer to the location that you have selected and prepared for its operation. 2-10 Phaser 600 Color Printer...
Page 28: Removing The Shipping Block
Installing the Printer and Drivers Removing the shipping block Note Make sure that you have access to all sides of the printer while you are setting it up. Open the top cover. Remove the shipping block (printhead restraint) from inside the printer.
Page 29: Attaching The Ink Loader
Insert the ink loader into the printer. At the rear of the ink loader, insert the thumbscrew into the opening to secure the ink loader to the printer; tighten the screw. 3-2628-14 Figure 2-6 Installing the ink loader 2-12 Phaser 600 Color Printer...
Page 30: Loading The Ink
Installing the Printer and Drivers Loading the ink Open the ink loader cover. Insert the black ColorStix ink sticks (8) into the appropriate slots for that color. Caution Load only one ink stick at a time in each slot; otherwise the ink sticks might jam.
Page 31 Align the screwholes of the longer end of the output bin with the screwholes in the front legs of the printer. Insert the screws into the holes and tighten with a 5 mm (7/32 in.) hex wrench. Figure 2-8 Installing the output bin 2-14 Phaser 600 Color Printer...
Page 32: Adjust The Leveling Legs
Installing the Printer and Drivers Adjust the leveling legs Lock the wheels, adjust the four leveling legs under the printer by unscrewing each to the desired height. 9480-43 Figure 2-9 Leveling the printer Test that the printer is level in the side-to-side and front-to-back axes. Installing the paper roll Open the paper cover.
Page 33 9480-36 Figure 2-11 Loading a media roll on the roll holder Reinstall the removable endcap; it ﬁts inside the paper roll. Tighten the plastic nut. 9480-37 Figure 2-12 Securing the roll on the roll holder 2-16 Phaser 600 Color Printer...
Page 34 Installing the Printer and Drivers Insert the paper roll holder into the printer as shown, with the ﬁxed end ( ) closest to the front panel ( 9480-38 Figure 2-13 Loading the roll in the printer Feed the paper into the slot; when the printer is ready, the printer will pick up the paper.
Page 35: Installing Options
Connect the printer to a host as detailed in the following topics. Note Carry spare serial and parallel cables and network adapters. You can use them if you encounter a defective cable or as an alternate means of testing the printer-to-host communications. 2-18 Phaser 600 Color Printer...
Page 36: Connecting The Printer
Installing the Printer and Drivers Connecting the printer Printer ports The printer is shipped standard with a bi-directional parallel port and a SCSI port for interfacing to the optional Phaser Copystation, or an external hard disk for font storage. In addition, the printer can be conﬁgured with optional networking and serial ports.
Page 37: Parallel Connection
To connect to the printer’s parallel port, a high-density bi-directional parallel cable is required. This cable is available from most computer cable vendors, and also as Tektronix part number 012-1468-00 (36-pin high-density printer to 25-pin DSUB PC cable). The printer supports a standard (uni-directional) parallel port. The parallel port can also be set for bi-directional communications.
Page 38: Phasershare™ Network And Serial Connections
All data input ports and network protocols are simultaneously active. Print jobs are processed on a ﬁrst-come, ﬁrst-served basis. To order the optional hardware, contact your local Tektronix reseller or call Tektronix toll-free in the United States at 1-800-835-6100.
Page 39: Turning On The Printer
Plug the power cord into the printer and into a grounded outlet. 9480-10 Figure 2-17 Attaching the power cord Turn on the power to any peripherals you have connected (such as a font disk or Phaser Copystation). Wait 1 minute, then turn on the printer. 2-22 Phaser 600 Color Printer...
Page 40 You can turn on the startup page using either the front panel menu or a software utility ﬁle provided on the CD-ROM or the Tektronix World Wide Web page. When the printer is ready for operation When the power-up sequence is complete, the green indicator is on steady (not blinking), the red indicator is off, and the front panel message reads Ready.
Page 41: Startup Page
The memory SIMM is not working. Since the printer’s base memory is still working, the printer can still be used, but large images may not print, special imaging features may not work and throughput may be reduced. 2-24 Phaser 600 Color Printer...
Page 42: Configuration Page
Tektronix version number of the 2015.105 PostScript PostScript ﬁrmware running on the version printer’s processor. Print engine FW Tektronix version number of the engine 1.0/1.0 Any value version number ﬁrmware running on the printer’s processor. Read from ROM and stored in NVRAM.
Page 43 Token Ring A unique address provided for each Hardware- In the format Address printer. dependent xx:xx:xx:xx:xx:xx Token Ring: Speed at which the ring is operating Speed Token Ring: Ring bridging method Adaptive Transparent, Source Route Bridging 2-26 Phaser 600 Color Printer...
Page 44 Installing the Printer and Drivers Table 2-1 Conﬁguration page settings (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM Token Ring: All Indicates default frame type for false true Routes broadcasts Broadcast Token Ring: Indicates connection state Connection- NoCable, Cable connected, Connection dependent Inserted, Removed, Duplicate...
Page 45 TCP/IP port Indicates the type of interpreter in use Not authorized, Disabled interpreter at the port RARP/BOOTP Used for setting the printer’s IP False True (Reverse address from a boot server. Address Resolution Protocol/Boot Parameter Protocol) 2-28 Phaser 600 Color Printer...
Page 46 Installing the Printer and Drivers Table 2-1 Conﬁguration page settings (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM IP Address The Internet Protocol address. If null, Not Set String of 15 or fewer the address will be set at run time via characters of the format RARP or BOOTP.
Page 47 SNMP authentication failure. SCSI Disk Indicates if a SCSI disk is attached to Internal On-line, total space, free the printer. Also indicates its storage Connected, space. Uninitialized. capacity and the amount of free space. External 2-30 Phaser 600 Color Printer...
Page 48 Installing the Printer and Drivers Table 2-1 Conﬁguration page settings (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM Execute Determine whether or not to run the Skip Sys/Start Job system start ﬁle during system initiation. Boot Delay Number of seconds the printer waits Any positive integer.
Page 49: Selecting A Language For The Front Panel
Press the right arrow button until the display shows the language you want from these selections: Language:English Language:Español Language:Français Language:Deutch Language:Italiano Language:(Japanese) Press to select the language. Press the button until Ready Select is displayed. 2-32 Phaser 600 Color Printer...
Page 50: Installing The Printer's Software
PostScript printer description (PPD) ﬁles. Refer to your applications’ documentation for details on using PPD ﬁles. Note To add PPDs for printers other than the Phaser 600 printer, open the WIN95_NT directory on the printer’s CD-ROM. Locate the printer’s PPD ﬁles: On the printer’s CD-ROM in the WIN95_NT directory.
Page 51 Select Network Printer if you are accessing your printer through a network. Click Browse to search the network and select a printer queue. Then click Next. In the window listing Manufacturers/Printers, click the Have Disk button. 2-34 Phaser 600 Color Printer...
Page 52 In the Open dialog box select the Drive for the Printer Software for Windows diskette. Click OK. A list of Tektronix printers appears. Select your printer in the list, then click Next. Select Tektronix Phaser 600 if you have the standard version of the printer.
Page 53 The ﬁles for this driver are available only on the printer’s CD-ROM. If you already have the driver installed and you are only adding a printer, such as the Phaser 600 printer, open the Control Panel, double-click the Adobe driver icon, then continue with Step 7.
Page 54 Select your printer, then click Next. Select Tektronix Phaser 600 if you have the standard version of the printer. Select Tektronix Phaser 600 with Extended Features if you have the printer’s Extended Features option. Note If you are not sure which conﬁguration of the printer you have, the printer’s startup page lists this information under Extended...
Page 55 Adobe PS 3 Driver diskette. If you already have the driver installed and you are only adding the Phaser 600 printer, open the Control Panel, double-click the Adobe driver icon, then continue with Step 5. If you already have the driver installed and you want to add a printer other than the Phaser 600 printer, open the Control Panel, double-click the Adobe driver icon, then continue with Step 5.
Page 56 At the message, click OK; the Control Panel opens. From the Control Panel, double-click Printers. In the Printers dialog box, select the Tektronix Phaser 600 printer you just installed, then click Connect. In the Connect dialog box, select the port the printer is connected to, then click OK.
Page 57 TK600171.PPD (for the standard version of the printer) TK600391.PPD (for the printer’s Extended Features option) Note If you are installing a Tektronix printer other than a Phaser 600 printer, copy the PRINTER.INF and printer PPD ﬁles from the WIN95_NT directory on the printer’s CD-ROM.
Page 58 Under Driver, scroll to the end of the list and select Other; the Install Driver dialog box appears. When prompted, do one of the following. If you are using the Phaser 600 CD-ROM: Type in the CD-ROM drive location, and the \WIN95_NT directory. Click OK; the Select Driver dialog box appears.
Page 59 Windows NT Setup dialog box appears. If you installed a PostScript printer in Step 4, follow this procedure to delete it. (Now that the Tektronix printer is installed, this printer is no longer needed.) Select the printer you want to remove.
Page 60 Installing the Printer and Drivers Installing ATM software Note ATM software is available only on the CD-ROM for the printer’s Extended Features option. Insert the printer’s CD-ROM into your computer’s CD-ROM drive. Click the Start icon in the taskbar on your screen. In the menu that appears, click Run.
Page 61: Macintosh Software
CD-ROM: Insert the Phaser 600 printer’s CD-ROM into your computer’s CD-ROM drive. Double-click the Phaser 600 Installer icon. Click Continue until the Easy Install window appears. To install the items listed in the Easy Install window, click Install. For details on each item, click Read Me.
Page 62 Click on the Zone your printer is in. See your network administrator if you have questions. Click on your Phaser 600 printer in the list of printers on the right side of the Chooser. Close the Chooser by clicking its close box.
Page 63 Setting up the Phaser 600 GX driver If you are using Apple Macintosh QuickDraw GX and System Software 7.5 or later, use the Phaser 600 GX driver to print to your Phaser 600 printer. The Phaser 600 GX driver works with QuickDraw GX and non-QuickDraw GX applications.
Page 64 The AppleTalk option is the standard network connection. The Servers option is used to select a shared desktop printer. Click on your Phaser 600 printer in the list of printers on the right side of the Chooser. Click the Create button to create a desktop printer. An icon of the printer appears on the desktop with the same name as the printer selected in the Chooser.
Page 65 If you are not sure which conﬁguration of the printer you have, the printer’s startup page lists this information under Extended Features: Yes/No. In the dialog box that appears, select the appropriate items under Installable Options then click OK. Click the Chooser’s close box. 2-48 Phaser 600 Color Printer...
Page 66: Workstation Users
UNIX workstation users can access utility ﬁles in the following ways: Install the ﬁles from the Tektronix Phaser 600 CD-ROM if your system includes a CD-ROM drive. Mount the PC diskette on the workstation (most workstations with 3.5-inch disk drives provide a device driver that allows you to mount...
Page 67: Installing The Printer Driver For Os/2 Version
LPT2PRIN. Scroll through the printer drivers listed to locate the proper Tektronix printer driver name. If it is listed, select it, otherwise, point the cursor to any other driver listed and click the right mouse button. Click Install from the menu options.
Page 68 Select Options and make sure that it is set to Phaser 600; if not, repeat the previous steps. While in this screen, set Job and Wait to 0, if they aren't already. Select the Output Tab; ensure that the proper port is selected.
Page 69: Configuring The Printer's Serial Port For A Pc
The device driver name in lp may be different depending upon which serial port the printer is connected to and the device driver naming scheme for the workstation. 2-52 Phaser 600 Color Printer...
Page 70: Configuring A Novell Netware Server For The Printer
Installing the Printer and Drivers Create a directory called /var/spool/px and create a ﬁle in the directory called if. The content of the ﬁle should look like this: #!/bin/sh /bin/cat Give the if ﬁle executable permission, type: chmod +x if If communication to the serial port uses 7 data bits, the value for xs changes as follows.
Page 71: Configuring Tcp/Ip
AppSocket, the printer language(s) supported by the printer (if the customer site uses AppSocket). syslog, a system’s log collect printer information for the network administrator. SNMP (Simple Network Management Protocol), allows the system administrator to query and control the printer’s status remotely. 2-54 Phaser 600 Color Printer...
Page 72 Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc. This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications.
Page 73: Users Safety Summary
Users safety summary Terms in manual: CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life. Power source: Do not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground.
Page 74: Service Safety Summary
Service safety summary For qualiﬁed service personnel only: Refer also to the preceding Users Safety Summary. Do not service alone: Do not perform internal service or adjustment of this product unless another person capable of rendering ﬁrst aid or resuscitation is present. Use care when servicing with power on: Dangerous voltages may exist at several points in this product.
Page 75: Verifying The Printer And Host Connections
Chapter Verifying the Printer and Host Connections In this chapter, you verify that the host computer can send ﬁles to the printer. This chapter assumes that the printer and the printer drivers have been properly installed as explained in the previous chapter, “Installing the Printer and Drivers.”...
Page 76: Windows 3.1 Driver Verification
Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 600 , (whichever applies) from the displayed list of available printer drivers. Click OK .
Page 77: Novell Netware Verification
(Point to any printer object, click the right mouse button, click on Select Default , and click on Phaser 600.) This is a simple way to be sure that all printers are set up correctly.
Page 78: Using The Error Handler Utility
This loads the error handling utility into the printer's memory where it remains until the printer is turned off. Send a ﬁle to the printer as explained in the previous procedure. If an error occurs, the printer will print a page listing the error. Phaser 600 Color Printer...
Page 79: Front Panel
Verifying the Printer and Host Connections Front panel These front panel features are found on the printer: A two-line, 24-character LCD Four push buttons Two LEDs LCD. The LCD serves two purposes: displaying current image processor and print engine status information and displaying an interactive menu. Status information includes image processor status such as Ready, Receiving Data and Printing.
Page 80: Verifying Printing From A Macintosh
Displayed on the right side of the dialog box are a list of printers that the selected driver will print to. Select the newly installed printer Phaser 600. (If, for example, a Phaser 600 printer is already on the network with the name Phaser 600, then the newly installed printer will be named Phaser 600-1.)
Page 81: Printing The Directory From A Macintosh
(such as both LocalTalk and Ethernet). Refer to Chapter 6, “Troubleshooting” for more information about networks. More troubleshooting tips are included in the reference manual Phaser 600 Drivers and Utilities Printing Reference. Printing the directory from a Macintosh Make sure that you have an open window displayed on the screen (such as the hard disk drive's window).
Page 82 If problems occur at this point, download the error handling utility to the printer as explained in the next procedure. Contact the Customer Support Hotline at 1-800-835-6100. Refer to the Phaser 600 User Manual. Each provides information on using the printer with speciﬁc applications.
Page 83: Verifying Printing From A Workstation
Verifying printing from a workstation Verifying and printing using the TCP/IP protocols The Phaser 600 accepts ﬁles from networked UNIX and VMS workstations using TCP/IP communications. The printer supports BSD UNIX 4.3, AT&T's UNIX System V with BSD 4.3 lpr extensions, and DEC VMS with Tektronix PhaserSym software.
Page 84 Verifying the Printer and Host Connections To print to the Phaser 600 printer in the VMS environment, you must have the symbiont PhaserSym running on the host. To print to the printer from the host, you must ﬁrst have the printer’s queue established. This is site-dependent and requires the aid of the site’s network administrator.
Page 85: Key Operator Training
Chapter Key Operator Training This chapter covers the last portion of the Tektronix Service Option S0 installation: Training the printer's key operator. The steps you follow here place an emphasis on encouraging the key operator to read and use the printer's user manual to operate, clean, and care for the printer.
Page 86: Printer Controls And Indicators
Network connections: Explain the different types of PhaserShare cards that provide printer connectivity. Show where these connections are explained in the user manual and where to ﬁnd more information about expanding their printing system with other network options, cables, and accessories. Phaser 600 Color Printer...
Page 87: Loading Consumables
Ink sticks: Demonstrate how to load an ink stick. Emphasize to customers to use only Phaser 600 printer ink sticks. The printer’s warranty will be voided if non-Tektronix ink sticks are used. Also emphasize that they should not use ink sticks that have large pieces missing and not to load any small broken pieces.
Page 88: Clearing Paper Jams
Show where this is explained in the user manual. Allow the inks in the printhead to solidify (about 15 minutes) before moving or tilting the printer. Demonstrate how to empty the waste bin. Phaser 600 Color Printer...
Page 89: Warranty Information
Customer Support Hotline If customers encounter problems while using their printer that cannot be resolved using the user manual, they can call Tektronix’ Customer Support Hotline for help. The Hotline can answer technical question regarding using the printer, ranging from printing from application software to technical speciﬁcations.
Page 90: Accessing The Printer's Web Page
Tektronix drivers and software. To access the BBS 24 hours a day, 7 days a week, call (503) 685-4504. Use 9600 baud, 8 bits, 1 stop bit, and no parity.
Page 91 Key Operator Training Before calling, instruct customers to write down the area code and telephone number for customers fax machine. HAL will ask customers to key this number through the keypad on their voice telephone. If they are calling from outside the United States or Canada, they’ll need to know the international access code to reach their country from the United States.
Page 92 Spain 00 34 area code fax number Sweden 00 46 area code fax number Switzerland 00 41 area code fax number just enter customer fax numbe Other countries 00 xx area code number Phaser 600 Color Printer...
Page 93: Tektronix Color Printer Information Server
If customers don’t have the means of transferring these ﬁles from the PC diskette, they can request ﬁles from the Tektronix Color Printer Information Server, an automatic ﬁle serving program on the Internet that responds to requests for ﬁles.
Page 95: 5 Theory Of Operation
Chapter Theory of Operation Overview This chapter covers the theory of operation of each subsystem within the printer: Functional block diagram Printhead maintenance cycle Print process in operation Service Manual...
Page 96: Functional Block Diagram
Fuser Power supply 9482-10 Figure 5-1 Overview of the printer All printer functions are centered around the engine control board. All DC voltages are routed through the engine control board to all other devices. Phaser 600 Color Printer...
Page 97 Theory of Operation Printhead The printhead is the heart of the printer. It is the device that actually places ink onto paper. The printhead contains the reservoirs for the ink it uses as well as a series of piezo-electric devices that squirt ink onto the paper. The printhead features 124 jet nozzles to force ink out of the printhead onto paper.
Page 98 Theory of Operation The core of the Phaser 600 printhead is the “jet stack” — a bonded pack of 14 etched stainless steel plates The active element in the jet stack is the piezo-electric crystal array that, when energized, ﬂexes to force a drop of ink out of a jet.
Page 99: Print Modes
Theory of Operation The printhead’s ink ﬂow from the supply chamber to the nozzle is signiﬁcantly different than aqueous printers. The ink in the Phaser 600’s printhead ﬂows past the piezo crystal and then to the ink jet oriﬁce (nozzle).
Page 100: Ink Loader
Ink sticks Ink load belt Ink stick Ink origin sensor low sensor Ink load motor Ink stick Printhead door motor drop sensor Printhead door Printhead Ink melt chamber Ink reservoir 9482-98 Figure 5-4 The ink loader Phaser 600 Color Printer...
Page 101: Maintenance Station
Theory of Operation Maintenance station Like ink-jet printers, the printer requires a maintenance station to keep the printhead jets working. The printer’s maintenance station performs four basic functions: Removes air bubbles from within the printhead after power up Removes ink and dust particles from the printhead’s faceplate Maintains meniscus control by preserving the anti-wetting properties of the printhead’s faceplate;...
Page 102: Maintenance Station Cam
The right-side track is used by the maintenance station’s cam pin to position the maintenance station against or away from the printhead, as well as operate the air valve. Phaser 600 Color Printer...
Page 103 Theory of Operation To perform the maintenance cycles, the drum will rotate counterclockwise to three different positions: Air knife, wipe, and purge. Purge Wipe Waste bin track Maintenance track Maintenance station pin Air knife 9482-97 Figure 5-6 The maintenance station cam For example, to perform a purge cycle: The drum is rotated counterclockwise to move the cam to the purge position which forces the maintenance station against the faceplate...
Page 104 Air knife while the printhead moves toward the maintenance station. Wipe while the printhead moves away from the maintenance station. Air knife while the printhead moves toward the maintenance station. 7-second jetting to clear the nozzles of contaminated ink. 5-10 Phaser 600 Color Printer...
Page 105 Theory of Operation Fuser After ink is deposited on the media it must be fused. Fusing increases the diffusion of ink droplets into the media and improves appearance and durability of the image. Using the printer driver, uses have the option of hot fusing, via a built-in heater element, cold fusing and no fusing at all, depending on the media being printed on and user preferences.
Page 106: Power Supply
The engine control board contains the drivers for the X-axis, Y-axis and fuser motors, the printhead heaters, and the fans. Lastly, the engine control board contains the A/D converters for controlling the printhead temperatures, monitoring power supply output, ink levels in the printhead and the fuser’s temperature. 5-12 Phaser 600 Color Printer...
Page 107: Print Process In Operation
Theory of Operation Print process in operation Media positioning The print process is preceded by the printer positioning and measuring the roll or sheet of media currently installed. When the paper input sensor detects a sheet of media inserted up to the upper feed rollers, the clamp-close solenoid are energized to close the spring-loaded clamp against the drum.
Page 108 ﬁrst inserted at the upper feed rollers. This way, new media can easily be exchanged for the currently installed media 5-14 Phaser 600 Color Printer...
Page 109 Theory of Operation Printing Printing begins with the same process described in the media positioning except the media is not unloaded. Also the clamp-close solenoids remain energized to hold the leading edge of media to the drum. The drum incrementally steps forward to allow the shutting printhead to print the image in swaths upon the paper.
Page 110 The Y-motor reverse to draw the paper remaining in the paper path back to the start position at the upper feed rollers. Stripper fingers Exit rollers Exit sensor Fuser shuttle 9482-106 Figure 5-10 Fusing the print 5-16 Phaser 600 Color Printer...
Page 111: Troubleshooting
Chapter Troubleshooting This chapter discusses troubleshooting the printer. Troubleshooting is discussed with two approaches: A step-by-step veriﬁcation procedure that systematically conﬁrms that particular components of a printer are properly functioning until a problem is found. A symptom/cause scheme that lists particular printer failures and error codes and their possible causes.
Page 112 The printer continues to heat the printhead to its normal operating temperature. A printhead cleaning cycle is performed once the printhead reaches its normal operating temperature. Once the cleaning cycle completes, the print engine is initialized. Phaser 600 Color Printer...
Page 113: Print Engine Troubleshooting
Troubleshooting Print engine troubleshooting This topic is a step-by-step procedure for systematically verifying particular aspects of a printer's operation. Following this procedure should lead to the cause of a printer's failure. Verifying image processor operation If the printer does not power up, or does not initialize, or the printer initializes but the motors do not run properly, go to the later topic, “Verifying power supply operation”...
Page 114: Verifying Print Engine Operation By Using Its Test Print
AC Input: With the VOM set to measure AC voltages, measure the power being supplied to the printer. It should measure between 85 to 132 VAC (110 VAC nominal) or 180 to 264 VAC (220 VAC nominal). Phaser 600 Color Printer...
Page 115 Troubleshooting DC Output: Refer to Appendix C, “Wiring Diagrams” for more details on other voltage test points. +5 VDC ± 0.25 +12 VDC ± 0.6 -12 VDC ± 0.6 +40 VDC ± 0.4 +78 VDC ± 2% (adjustable from 68 to 102 VDC) -78 VDC ±...
Page 116: Testing For A Shorted Dc Supply
Measure for a +5 volt short at J101 pins 1 and 3. If a short is found, replace the engine control board. Measure for a +12 volt short at J101 pins 1 and 6. If a short is found, replace the cooling fan. Phaser 600 Color Printer...
Page 117: Testing Motor And Solenoid Resistances
Troubleshooting Testing motor and solenoid resistances Turn off the printer and disconnect the power cord. With a VOM set for measuring resistance, test each motor's windings for correct resistance (disconnected from the printer). Rotate the motor's drive shaft slightly while taking the measurement. Also carefully inspect each motors wiring harness to ensure it is not damaged and shorting out to the chassis.
Page 118: Media Jams And The Paper Path
“Testing for a shorted motor” on page 6-6. Otherwise, go to Step 4. Refer to the later topic, “PC-based diagnostics” on page 6-26. Use the motor and solenoid test to check the operation of the paper load system. Phaser 600 Color Printer...
Page 119 Troubleshooting Print feed jams -- internal jam error Paper feed jams, noted as internal jams, occur if the left or right of the paper is less than 8 mm (1.3 in.) from the respective end of the drum, or the left or right edge of the media cannot be detected at all by the printhead’s left and right paper-edge sensors.
Page 120 0.1 mm to 0.075 mm (0.004 to 0.003 in.) Ensure that the fuser motor is properly tensioned and its belts are in good condition. Check that the exit sensor is working correctly. Check that the fuser door is properly latched. 6-10 Phaser 600 Color Printer...
Page 121: Printing And Print Quality Problems
Troubleshooting Exit jams An exit jam occurs when the media has not been detecting exiting the printer when it should have. Ensure the media being used is in good shape, with not torn or ragged edges that could jam in the paper path. Inspect the paper path for obstructions.
Page 122 The X-axis drive is not functioning correctly. If the X-axis drive does not slew the printhead smoothly and evenly during printing, vertical lines appear in the print. Replace the X-axis drive, if indicated. Replace the X-axis drive assembly. 6-12 Phaser 600 Color Printer...
Page 123 Troubleshooting Streaks or lines in the print parallel to the printhead travel Possible missing weak jet. Print the Service Test Print 2 “Weak Jet” to determine if a jet is not performing. Perform a printhead cleaning cycle to try to clean a clogged jet. If necessary, turn off the printer and allow the printhead to cool for 3 hours.
Page 124 The printhead high voltage may be adjusted too high; refer to the Chapter 9 topic “Adjustments” on page 9-4. 6-14 Phaser 600 Color Printer...
Page 125 Troubleshooting Inconsistent printing This failure is probably caused by an electronic failure. Possible causes are a poor electrical connection at the carriage board an engine control board failure or a poor ground. Also check the printhead drive voltage; see Chapter 9, “Printhead drive voltage adjustment” on page 9-15.
Page 126: Troubleshooting Missing Or Deflected Jets
Clean the wiper with an alcohol-moistened foam swab. Never scrape it with a tool or with your ﬁngertip. Following a printhead cleaning cycle the wiper is warm and the ink wipes off easily. 6-16 Phaser 600 Color Printer...
Page 127 Troubleshooting If the problem persist, a “freeze/thaw” cycle may remove the obstruction. Turn the printer off and allow it to cool for at least 3 hours. Then turn it on again. During the cycle, ink in the nozzles solidiﬁes and is forced out by expanding ink when the ink is remelted. Purge three times after a freeze cycle, if necessary.
Page 128 A0, A1 and A2. Only A2 should have a jumper installed; this sets the SCSI to 4. Ensure no external hard drive uses SCSI address 4. Replace the hard drive. Upon power-up the image processor automatically checks, and if necessary, initializes the internal hard drive. 6-18 Phaser 600 Color Printer...
Page 129: Error Codes And Messages
Troubleshooting Error codes and messages Engine board LEDs Engine error codes can be read either at the front panel or at the print engine control board. The error code is displayed as a numeric value on the front panel. A log of error codes is viewable in the menu item Service Support — Fault History (fault 1 is the most recent).
Page 130 Replace the engine control board. Out synchronous fuser The movement of the fuser motor is impeded. Check or replace the motor and its wiring harnesses. Replace the engine control board. Check that the fuser carriage moves freely. 6-20 Phaser 600 Color Printer...
Page 131 Troubleshooting Table 6-3 Engine error codes reported to the front panel (cont'd.) Code Descriptions Possible causes Out synchronous Y-axis The movement of the Y-motor is impeded. Check or replace the motor and its wiring harnesses. Replace the engine control board. Check that the paper clamp is not jammed, keeping the drum from rotating.
Page 132 Fuser heater 1 A/D failure Failure of the A/D circuits. Replace the engine control board. unused NVRAM checksum error Replace the engine control board. SCSI Hard Drive Failure Check the hard drive connections. Replace the hard drive. 6-22 Phaser 600 Color Printer...
Page 133 Troubleshooting Table 6-3 Engine error codes reported to the front panel (cont'd.) Code Descriptions Possible causes Dot Clock Check Failure The print engine did not successfully complete a scan of the dot clock encoder strip. Ensure the strip is clean and properly in place and the sensor under the carriage board is in position to read the strip.
Page 134 PWA -- select the PWA group from the front panel. IP Board Test -- select the IP Board Group. Engine -- select the Engine group from the front panel. Note Notice you can use Test 1a to reset the image processor’s NVRAM. 6-24 Phaser 600 Color Printer...
Page 135 Troubleshooting Table 6-4 Image Processor Service Mode tests Test Function CPU Interrupt Instruction ROM Checksum NVRam Acknowledge NV Register Write Read NV Clear (Zero entire device) PROM Data Read Font ROM Checksum Centronics Register Write Read Centronics LoopBack (external) TC8576 CTS veriﬁcation TC8576 External Loopback SCSI Interrupt SCSI Register Write Read...
Page 136: Pc-Based Diagnostics
The following procedure discusses using the diagnostics with an Apple PowerBook running SoftWindows, as this is the portable computer in use by the ﬁeld service organization. SoftWindows should be set to the Preferred size of 10 Mbytes, assuming your PowerBook has enough RAM. 6-26 Phaser 600 Color Printer...
Page 137: Starting The Diagnostics
Troubleshooting Starting the diagnostics Turn off the printer and the computer from which the diagnostics will be run. Connect the serial port of the computer to the special diagnostic, 5-pin serial port of the printer; use the special serial cable adapter.
Page 138 If the status does not change to “ok,” then make sure the serial cable is properly installed and that the program is using the correct serial port (usually this is COM1:) and the correct baud rate (19.2K baud). 6-28 Phaser 600 Color Printer...
Page 139 Troubleshooting Once communication with the printer is made, the diagnostics display the following screen on the computer: Figure 6-4 PC-based diagnostics screen display The start-up screen features the following elements: A conventional-looking Menu Bar across the top of the screen; all diagnostic functions are accessible via this menu.
Page 140 Alt-R (Control R — Mac) – select the currently highlighted test opens the Run window to prepare to execute the currently selected tests. 6-30 Phaser 600 Color Printer...
Page 141 Troubleshooting Alt-H (Control H — Mac) – Opens a small Help window which serves to remind the functions that are available. Escape or Enter removes the Help window. Figure 6-5 The diagnostics global help screen F1 – Brings up a more complete description about the currently highlighted test.
Page 142: Running Tests
Press the Return key to enter the test group selection window. Use the arrow keys to scroll through the list of tests suites. Press the Tab key to select a test suite. Figure 6-6 The Test Suite list 6-32 Phaser 600 Color Printer...
Page 143 Troubleshooting Once you select a test suite, the individual tests of that suite are displayed. Figure 6-7 The Individual test within a selected test suite Press the space bar to select or deselect a test. You can select as many tests as you like.
Page 144 Figure 6-9 An Individual Test help screen The Sensor Test shows you the real-time state of the printer’s sensors. You can manually interrupt the sensors to determine if they operate correctly. Figure 6-10 Sensor Test summary 6-34 Phaser 600 Color Printer...
Page 145 Troubleshooting The Servo Motor Tests let you know if a motor motion occurred within its expected time frame. The test reports if the motor passed or failed. Figure 6-11 Test result of a Servo Motor Test The Heater and Ink Levels Tests let you select, start and observe the operation of the printers heaters and determine if they are operational.
Page 146: Saving And Restoring Test Selections
Any user-conﬁgurable setting that the program knows about is saved in a conﬁguration ﬁle called DIAGS.INI and persists from session to session. Presently there is a short list of conﬁgurable items, but any program setting you makes need only be done once. 6-36 Phaser 600 Color Printer...
Page 147: The Diagnostic Pull-Down Menus Summary
Troubleshooting The diagnostic pull-down menus summary All of the functionality in the user interface is accessible from the menu bar. Some of the functions are additionally available via “accelerator” key (Alt- key) synonyms. The following discusses the pull-down menus, as they appear, left to right.
Page 148 About – gives the program version and other statistics about its operation. Usage overview – gives the user an overview of the system and explains running the ﬁrst test. F1 – describes an individually highlighted test. 6-38 Phaser 600 Color Printer...
Page 149: Problems And Solutions
Macintosh printing problems Table 6-6 Macintosh printing problems Image never prints. Make sure that the correct Phaser 600 icon was selected in Printer acts as if it is the Chooser. Try printing the job again. receiving data, but nothing comes out of In the Chooser, switch background printing to off .
Page 150: Pc Dos Printing Problems
PostScript mode. Use the utility located on the Tektronix diskettes to change language emulation. Refer to the Phaser 600 Color Printer User Manual for complete instructions. Download TEKEHAND.PS ﬁle located on the Tektronix Utilities diskette.
Page 151: Windows Printing Problems
(CMY), blue is often printed as purple. To adjust blue from within Microsoft Windows: Within the Tektronix PostScript Windows driver you have an option, Vivid Color, that alters to blue colors that are appearing purple. To Access this option, select:...
Page 152: Workstation Printing Problems
(even if the startup up page had been turned off). Soft errors include failures of the expansion SIMMs, as well as the SCSI, serial, LocalTalk, parallel, and Ethernet ports and their cabling or connections. 6-42 Phaser 600 Color Printer...
Page 153: Cleaning And Maintenance
Chapter Cleaning and Maintenance Cleaning hints Power can remain ON while cleaning. Use isopropyl alcohol that is at least 90% pure (99% yields the best results). Cleaning Kit (016-1400-00) includes the following items: Cleaning tool Foam cleaning swabs Lint-free cleaning cloth Empty bottle for isopropyl alcohol You can separately order a pack of 10 pre-soaked alcohol cloths (006-7824-00) Quick cleaning...
Page 154 Using your hand, rotate the drum toward the back of the printer to expose and clean more of the drum; clean its entire surface in this manner. 9480-16 Phaser 600 Color Printer...
Page 155: Back Tension Blade And Paper Clamp
Cleaning and Maintenance Back tension blade and paper clamp Clean the back tension blade and paper clamp when you notice streaks on your print. Setting the front panel for cleaning On the printer’s front panel, press the Menu button; the printer displays this message: Help Pages <----...
Page 156 Clean one section of the blade by wiping back and forth 3-4 times with pressure. Switch hands to clean the other end of the blade. 9480-19 Phaser 600 Color Printer...
Page 157 Cleaning and Maintenance Note If the blade is especially dirty, you may need to add more alcohol to the lint-free cloth or use a new cloth. Cleaning the paper clamp Caution Make sure that you have set the printer’s front panel to Clean Clamp ;...
Page 158: Clamp Rollers
Caution Do not pull the rollers. away from the drum. The metal that attaches it to the printer is very ﬂexible and can be permanently bent. Repeat Step for each of the 14 rollers. 9480-21 Phaser 600 Color Printer...
Page 159: Fuser Shuttle And Exit Rollers
Cleaning and Maintenance Fuser shuttle and exit rollers When you notice streaks parallel to the direction of fusing in the prints, you can do the following: Clean the fuser shuttle and clean or replace its components Clean the exit rollers The fuser kit contains these replaceable parts: 2 foam oiler wheels Replace when you notice ink buildup on the fuser wheel.
Page 160 Hold the exit cover and rotate it down. The fuser shuttle is visible on the far right inside the printer. Removing the fuser’s components Remove the foam oiler wheel by lifting it out of the printer. 9480-25 Phaser 600 Color Printer...
Page 161 Cleaning and Maintenance Remove the fuser wheel. 9480-31 Remove the cutter: Warning The cutter blade is sharp. To avoid injury, always handle it by its shaft or yellow protective cover. Slide the lever on the cutter to unlock it. Lift the cutter out of the printer. 9480-30 If you are replacing the fuser’s components, dispose of the old components as normal ofﬁce waste.
Page 162 Be careful not to get any alcohol on the front and rear rails of the fuser shuttle. It is oiled for smooth travel and the alcohol will remove the lubricant. If you are not replacing the fuser wheel, wipe it with a dry, lint-free cloth. 9480-45 7-10 Phaser 600 Color Printer...
Page 163 Cleaning and Maintenance Cleaning the shuttle rails and exit rollers Clean the exit rollers and shuttle rails whenever you clean the fuser shuttle or replace its components. Using a dry, lint-free cloth, wipe the shuttle rail and the “shelf” under the rubber belt.
Page 164 Inserting the cutter blade into its slot on the fuser shuttle, making sure that the exposed blade is facing up, as shown: 9480-46 Secure the cutter by sliding the locking lever. 9480-61 7-12 Phaser 600 Color Printer...
Page 165 Cleaning and Maintenance Insert the foam oiler wheel into its slot on the fuser shuttle. 9480-28 Insert the fuser wheel into its slot on the fuser shuttle. 9480-31 Service Manual 7-13...
Page 166: Clearing An Ink Jam
9480-64 If an ink stick doesn’t drop completely Use tweezers to pull the ink stick out of the printhead or use a pen or pen-like object to push the ink stick into the printhead. 9480-33 7-14 Phaser 600 Color Printer...
Page 167 Cleaning and Maintenance Cleaning the printhead and head wiper If your prints have missing dots in a vertical row or a missing horizontal line, ﬁrst clean the printhead, using the front panel menu function: Press the Menu button on the front panel. Press an arrow button (--->) until the front panel displays this message: Utilities...
Page 168 Clean the head wiper with an alcohol-dampened swab only. 9480-47 Close the top cover. Make a test print from the front panel. If the problem does not clear, replace the printhead. 7-16 Phaser 600 Color Printer...
Page 169: Repacking And Moving The Printer
Cleaning and Maintenance Repacking and moving the printer Before you begin Empty the waste bin as described below; then turn the printer off. Let the printer cool down for 7 minutes before you move it so that the ink has time to solidify. Cables and media Remove the power cord and any network cables.
Page 170: Repack The Printer
Clean-up Wipe off any dirt, dust, or oil in and around the printer. Close all doors and secure them with adhesive tape. Repack any other accessories in the original Tektronix shipping box(es). Repack the printer Re-insert the shipping block (printhead restraint) to secure the printhead.
Page 171 Tektronix shipping box with the appropriate packing materials. Call Tektronix at 1-800-835-6100 or call your nearest Tektronix dealer if you need a replacement box. Also, if you are returning the printer for service, call Tektronix or your nearest Tektronix dealer for a return authorization number. Inspection Rollers: Replace the rollers when you see any of the following defects: Flat spots.
Page 172 Apply grease to the cam pin in the cam gear’s pin groove. White (nylon) plastic bearings and cams: No lubrication required. 7-20 Phaser 600 Color Printer...
Page 173: Required Tools
067-1433-99 Rheolube grease (gears) 006-2037-00 Velocite 10 Lubricating Oil (rails) 006-7056-00 Anti-static mat 006-7056-00 Replacement cable ties 343-0549-00 Volt-ohm-meter such as a Tektronix DM252/4 Multimeter Magnifying lens such as Micronta (Radio Shack) Cat# 63-851 Metric Allen (hex) wrenches Service Manual...
Page 174: Printer Cabinet
Standoff Roll cover Standoff with shoulder 9482-24 Figure 8-1 Removing the roll cover Reverse these steps to reinstall the roll cover. Support the weight of the cover while you thread the screws into the printer frame. Phaser 600 Color Printer...
Page 175: Left Cover
Field Replaceable Unit Disassembly/Assembly Left cover Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove all the ink sticks from the ink loader. At the rear of the ink loader, remove the screw securing the ink loader to the printer cabinet.
Page 176: Right Cover
End cap screws Right cover Cover screws Right end cap Cover screws 9482-26 Figure 8-3 Removing the right cover Reverse these steps to reinstall the right cover. Phaser 600 Color Printer...
Page 177: Top Cover
Field Replaceable Unit Disassembly/Assembly Top cover Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Open the top cover. Remove the inner plate (9 screws) from the inside of the top cover. Disconnect the ribbon cable from the top cover’s interconnect board.
Page 178: Fuser Motor
Figure 8-5 Removing the fuser motor Reverse these steps to install the fuser motor. Tension the fuser motor belt to 4 kgs (9 lbs) as detailed in the Chapter 9 topic, “Fuser belt tension” on page 9-6. Phaser 600 Color Printer...
Page 179 Field Replaceable Unit Disassembly/Assembly X-axis (printhead) motor and X-axis belt Tools required #1 POSIDRIV® screwdriver Flat blade screwdriver Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the right cover as explained in the earlier procedure, “Right cover”...
Page 180 At the left end of the printer frame, remove the two screws securing the X-axis motor to its bracket. Remove the motor. X-axis motor Disconnect wiring harness Screws 9482-30 Figure 8-7 Removing the X-axis (printhead) motor Phaser 600 Color Printer...
Page 181 Field Replaceable Unit Disassembly/Assembly X-axis (printhead) belt Remove the two screws securing each end of the X-axis belt to the carriage board. Screws X-axis belt ends 9482-31 Figure 8-8 Removing the X-axis (printhead) belt Carefully free the X-axis belt from the X-axis belt pulleys and remove the belt.
Page 182 At the left end of the printer, remove the four screws securing the Y-axis motor bracket to the printer frame. Remove the motor and bracket. Screws Disconnect Y-axis wiring harness motor 9482-32 Figure 8-9 Removing the Y-axis (drum) motor 8-10 Phaser 600 Color Printer...
Page 183 Field Replaceable Unit Disassembly/Assembly Y-axis motor belt and Y-axis drum drive belt Loosen the Y-axis drum drive belt tensioner. Remove the outer drum bearing on the left end of the drum shaft. The bearing is held in place by two screws. Remove the screws securing the outer plate of the left drum frame.
Page 184 Disconnect the head-to-media motor’s wiring harness from the right junction board. Remove the two screws securing the head-to-media motor. Remove the motor and belt. Head-to-media Screws motor 9482-34 Figure 8-11 Removing the head-to-media motor Reverse these steps to reinstall the motor. 8-12 Phaser 600 Color Printer...
Page 185 Field Replaceable Unit Disassembly/Assembly Head maintenance cam gear motor Tools required 2.5 mm hex wrench Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the right cover as explained in the earlier procedure “Right cover”...
Page 186: Removing The Printhead
In order to not drastically alter the printhead tilt alignment, do not loosen the left-side tilt-adjusting screw. Supporting the printhead, gently remove the printhead’s hybrid ﬂex cable from its connector on the carriage board. 8-14 Phaser 600 Color Printer...
Page 187 Field Replaceable Unit Disassembly/Assembly Tilt the printhead back and gently free it from the rear rail. Ensure slide ramp is Back out the right- over to the printer's right side tilt-adjusting so the printhead moves screw back from the drum Disconnect the Gently free the sensors and...
Page 188: Installing The Print Head
Supporting the carriage board, gently insert the hybrid cable into its connector on the carriage board. Printhead Hybrid Carriage cable Tailpiece bearing Rear Plastic protector carriage rail 9482-37 Figure 8-14 Connecting the printhead’s hybrid cable 8-16 Phaser 600 Color Printer...
Page 189 Field Replaceable Unit Disassembly/Assembly Pick up the printhead and remove the plastic protector from underneath. Position the printhead above the rear rail and press the printhead's (concaved shape) tailpiece bearing in place on the rail. Ensure the bearing is properly placed between the retaining ribs of the tailpiece.
Page 190 “Printhead drive voltage adjustment” on page 9-15. Adjust the printhead’s head-to-media spacing using the Chapter 9 procedure “Printhead-to-media adjustment (tailpiece adjustment)” on page 9-15. Adjust for printhead tilt. Refer to the Chapter 9 topic “Tilt adjustment” on page 9-24. 8-18 Phaser 600 Color Printer...
Page 191: Maintenance Station
Field Replaceable Unit Disassembly/Assembly Adjust for bi-directional alignment using the Chapter 9 topic “Bi-directional print convergence” on page 9-21. Adjust for temperature offset. Refer to the Chapter 9 topic “Temperature offset adjustment” on page 9-28. Adjust the printhead’s left and right edge-detection sensors using the PC-based diagnostics.
Page 192 Field Replaceable Unit Disassembly/Assembly Disconnect the maintenance station wiring harness from the interconnect board on the side of the printer frame. Disconnect wiring harness Disconnect Air pump air hoses 9842-39 Figure 8-16 Disconnecting the maintenance station 8-20 Phaser 600 Color Printer...
Page 193 Field Replaceable Unit Disassembly/Assembly Remove the retainer holding the maintenance station's left pivot pin. Unpin the left and right ends of the maintenance station. Release the maintenance station guide pin from the maintenance station cam gear. Remove the maintenance station; pull out the air hoses and wiring harness with it.
Page 194: Replacing The Maintenance Station Wiper
Also, ensure that the edge of the wiper element is parallel to the face of the maintenance station. Clean the wiper with an alcohol-moistened swab. Maintenance station Wiper Wiper Ridge retainer element 9482-41 Figure 8-18 Replacing the wiper element 8-22 Phaser 600 Color Printer...
Page 195: Drip Plate
Field Replaceable Unit Disassembly/Assembly Drip plate Tools required #1 POSIDRIV® screwdriver Small needle-nose pliers Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Allow the drip plate to cool; this takes about 10 minutes. Remove the right cover as explained in the earlier procedure, “Right cover”...
Page 196 Brass spacer Drip plate C-clips 9482-42 Figure 8-19 Removing the drip plate Reverse these steps to install the drip plate. For reassembly, note the spacer slides over the lower rod. 8-24 Phaser 600 Color Printer...
Page 197: Air Pump
Field Replaceable Unit Disassembly/Assembly Air pump Tools required #1 POSIDRIV® screwdriver Diagonal cutters Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the right cover as explained in the earlier procedure, “Right cover”...
Page 198: Ink Loader
At the rear of the ink loader, remove the screw securing the ink loader to the printer cabinet. Lift and remove the ink loader. Ink Loader Finger screw 9482-44 Figure 8-21 Removing the ink loader 8-26 Phaser 600 Color Printer...
Page 199 Field Replaceable Unit Disassembly/Assembly Ink loader motor assembly Remove the ink loader as described in the previous procedure. Remove the left cover as explained in the earlier procedure “Left cover” on page 8-3. Disconnect the wiring harness leading to the ink loader motor assembly.
Page 200 Manually slide the printhead under the ink loader to endure it passes under the ink loader with interference. Ink loader motor assembly Ink loader alignment jig Printhead rails 9482-108 Figure 8-23 Installing the ink loader motor assembly 8-28 Phaser 600 Color Printer...
Page 201 Field Replaceable Unit Disassembly/Assembly Clamp (bail) roller assembly Tools required #1 POSIDRIV® screwdriver 2 mm hex wrench Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Open the top cover. Using a hex wrench, remove the two thumbscrews (one at each end) securing the clamp roller in place against the rear of the drum.
Page 202 Remove the retainer screw from the left end of the back-tension blade. Remove the retainer from the right end of the back-tension blade. Loosen the two set screws at the right end of the head-to-media set mechanism’s sleeve. Remove the head-to-media drive shaft from the sleeve. 8-30 Phaser 600 Color Printer...
Page 203 Field Replaceable Unit Disassembly/Assembly Remove the back tension blade retainer; it is held in place by one screw. Retainer screw Loosen two set screws Retainer Head-to media drive shaft 9482-47 Figure 8-25 Removing the back tension blade Slide the back tension blade assembly slightly to the right to free the left end.
Page 204 Remove the back tension blade as explained in the previous procedure, “Back-tension blade” on page 8-30. Remove the Y-axis motor as explained in the earlier procedure, “Y-axis (drum) motor and belts” on page 8-10. The Y-axis belts will be removed in following steps. 8-32 Phaser 600 Color Printer...
Page 205 Field Replaceable Unit Disassembly/Assembly Remove the left outer drum bearing on the left end of the drum shaft. The bearing is held in place by two screws. Remove the screws securing the outer plate of the left drum frame. The screws secure the outer plate to the six frame standoffs. Remove the plate.
Page 206 Loosen the right drum bearing on the right end of the drum shaft. The bearing is held in place by two screws. Disconnect the wiring harnesses leading to the paper clamp sensors mounted on the right roll holder. 8-34 Phaser 600 Color Printer...
Page 207 Field Replaceable Unit Disassembly/Assembly Remove the right roll holder. It is held in place by four screws. For reassembly, note how the drip plate rod passes through the back of the roll holder Right roll holder Right drum bearing Wiring harness 9482-48 Figure 8-27 Removing the right drum bearing...
Page 208 1/8 of a turn. Perform the drum alignment check described in Chapter 9, “Drum alignment” on page 9-19. Then tighten the screws. Following this complete the reassembly. 8-36 Phaser 600 Color Printer...
Page 209 Field Replaceable Unit Disassembly/Assembly Fuser and fuser belts Tools required #1 POSIDRIV® screwdriver 2.5 mm hex wrench Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the left cover as explained in the earlier topic, “Left cover” on page 8-3.
Page 210 With a hex wrench, remove the two screws securing each end of the fuser to the printer frame. Tilt forward and remove the fuser. The fuser motor belt is freed as you remove the fuser. Fuser 9482-51 Figure 8-29 Removing the fuser 8-38 Phaser 600 Color Printer...
Page 211 Field Replaceable Unit Disassembly/Assembly Fuser belt Flip up the tension adjust screws to loosen the tension on the fuser belt. Unhook each end of the fuser belt from the fuser shuttle. Remove the belt. Fuser shuttle Flip up tension adjuster to release belt tension Adjusting screws...
Page 212: Paper Clamp
Figure 8-31 Removing paper clamp Reverse these steps to reinstall the paper clamp. Ensure the clamp is correctly spaced and aligned to the drum by following the Chapter 9 procedure, “Paper clamp alignment” on page 9-11. 8-40 Phaser 600 Color Printer...
Page 213 Field Replaceable Unit Disassembly/Assembly Timing fence (dot clock encoder) Tools required #1 POSIDRIV® screwdriver Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the left cover as explained in the earlier topic, “Left cover” on page 8-3.
Page 214 Remove the two screws securing the timing fence to the printer frame. Carefully, lift to the left and remove the timing fence. Remove screws at both ends of timing fence Figure 8-32 Removing the timing fence Reverse these steps to reinstall the timing fence. 8-42 Phaser 600 Color Printer...
Page 215: Stripper Finger Assembly
Field Replaceable Unit Disassembly/Assembly Stripper ﬁnger assembly Tools required #1 POSIDRIV® screwdriver Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the roll cover as described in the topic, “Roll cover” on page 8-2.
Page 216 Bottom roller Screws guide 9482-57 Figure 8-34 Removing the lower roller assembly Reverse these steps to reinstall the lower roller guide. Ensure the “ﬁngers” of the guide ﬁt squarely through the holes in the paper clamp. 8-44 Phaser 600 Color Printer...
Page 217: Umbilical Cable
Field Replaceable Unit Disassembly/Assembly Umbilical cable Tools required #1 POSIDRIV® screwdriver Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the left cover as explained in the earlier topic, “Left cover” on page 8-3.
Page 218 Carriage board Cable retainer Umbilical Disconnect cable umbilical cable 9482-58 Figure 8-35 Removing the umbilical cable Free the umbilical cable from the printer frame. Reverse these steps to reinstall the umbilical cable. 8-46 Phaser 600 Color Printer...
Page 219 Field Replaceable Unit Disassembly/Assembly Sensors Tools required #1 POSIDRIV® screwdriver #0 POSIDRIV® screwdriver Skew sensors There are three skew sensors. Each is located on one of the paper guides of the upper roller assembly. Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity.
Page 220 Remove the two screws securing the sensor to the paper guide. Remove the sensor. Paper guides Remove 9 screws Skew sensors 9482-59 Figure 8-36 Removing the paper width sensors Reverse these steps to reinstall the skew sensors. 8-48 Phaser 600 Color Printer...
Page 221 Field Replaceable Unit Disassembly/Assembly Left fuser-closed sensor Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the left cover as detailed in the topic, “Left cover” on page 8-3. Disconnect the left fuser-closed sensor’s wiring harness from the left junction board.
Page 222 Free the sensors from their plastic mounting brackets on either side of the printhead. Left & right printhead sensors Disconnect wiring harnesses 9482-61 Figure 8-38 Removing the left and right printhead sensors Reverse these steps to install the left and right printhead sensors. 8-50 Phaser 600 Color Printer...
Page 223 Field Replaceable Unit Disassembly/Assembly Top cover sensors There are three top cover sensors: One sensor, mounted on the right top cover hinge, detects if the top cover is open. Two others, mounted at the left and right ends of the cover, detect if the top cover release lever is actuated (top cover unlocked).
Page 224 Remove the two screws securing the sensor to the waste bin frame. Screws Waste bin sensor 9482-63 Figure 8-40 Removing the waste bin sensor Reverse these steps to install the waste bin sensor. 8-52 Phaser 600 Color Printer...
Page 225: Exit Sensor
Field Replaceable Unit Disassembly/Assembly Exit sensor Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the lower front cover. It is held in place with four screws. Disconnect the exit sensor’s wiring harnesses from the right junction board.
Page 226: Circuit Boards
Unclip the front panel from the inside of the front panel bezel. Front panel 9482-65 Figure 8-42 Removing the front panel Reverse these steps to reinstall the front panel. 8-54 Phaser 600 Color Printer...
Page 227 Field Replaceable Unit Disassembly/Assembly Power supply Turn off the printer. Disconnect the power cord from the back of the printer. Remove the output bin. Open the card cage by removing the 10 screws securing it to the underside of the printer frame. Disconnect the AC wiring harness connecting to the power supply.
Page 228 Figure 8-44 Removing the engine control board Reverse these steps to install the engine control board. Note To retain printer calibrations and preference values, transfer the NVRAM chip, U6, from the old board to the new board. 8-56 Phaser 600 Color Printer...
Page 229 Field Replaceable Unit Disassembly/Assembly Downloading new engine control board ﬁrmware Turn off the printer. Remove the output bin. Open the electronics bay. Insert the PCMCIA card in the card receptacle, J110, on the engine control board. Turn on the printer. The LEDs on the engine board will all turn on and then turn off.
Page 230: Carriage Board
Supporting the printhead carriage, disconnect the printhead’s sensor and heater wiring harnesses from the carriage board. Remove the printhead as detailed in the earlier procedure, “Printhead” on page 8-14. Disconnect and free the umbilical cable from the carriage board. 8-58 Phaser 600 Color Printer...
Page 231 Field Replaceable Unit Disassembly/Assembly Remove the four screws securing the carriage board to the carriage. Remove the carriage board. Printhead assembly Five sensor and heater wiring Hybrid flex cable harnesses Four screws Carriage Tilt adjusting hex screw Rear rail Front rail X-axis belt Umbilical cable Carriage board...
Page 232 Field Replaceable Unit Disassembly/Assembly Reverse these steps to install the carriage board. Ensure the jumpers on the carriage board are correctly set for the Phaser 600 Color Printer. J362 J363 Phaser 300 Phaser 600 Phaser 300 Phaser 600 0052-01 Figure 8-46 Jumpers on the carriage board...
Page 233 Field Replaceable Unit Disassembly/Assembly Junction boards Right junction board Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the right cover as explained in the earlier procedure, “Right cover” on page 8-4. Disconnect the 14 wiring harnesses leading to the right junction board.
Page 234 Remove the four screws securing the left junction board to the printer frame. Remove 11 wire harnesses Left junction board location Remove four screws Junction board 9482-70 Figure 8-48 Removing the left junction board Reverse these steps to install the left junction board. 8-62 Phaser 600 Color Printer...
Page 235: Image Processor Board
Field Replaceable Unit Disassembly/Assembly Image processor board Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Disconnect all host interface cables and SCSI cables from the rear of the image processor board. Remove the six screws securing the image processor board to the rear of the printer’s card cage.
Page 236 PhaserShare Card Printer ID ROM NVRAM PostScript ROM SIMM RAM SIMM 2 Extended Feature SIMM RAM SIMM 1 9482-117 Figure 8-50 Transfer components from the image processor board 8-64 Phaser 600 Color Printer...
Page 237: Ram Simm
Field Replaceable Unit Disassembly/Assembly RAM SIMM Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the image processor board as detailed in the previous procedure, “Image processor board” on page 8-63. Connector SIMM 1 should always be ﬁlled with an 8 Mbyte RAM SIMM.
Page 238 Reinstall the image processor board into the printer. Reconnect the host interface cables. Turn on the printer and print the startup page; it indicates the feature set of the Extended Features SIMM in the printer. 8-66 Phaser 600 Color Printer...
Page 239: Postscript Code Rom Simm
Field Replaceable Unit Disassembly/Assembly PostScript code ROM SIMM Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the image processor board as detailed in the previous procedure “Image processor board” on page 8-63. Remove the RAM SIMMS and Extended Features SIMM (if installed) by spreading apart the pawls securing each end of the SIMMs in their connectors.
Page 240: Network Card
Reinstall the Extended Features SIMM (if removed) and RAM SIMM(s). Reinstall the image processor board into the printer. Reconnect the host interface cables. Turn on the printer and print the startup page. Network card Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity.
Page 241: Hard Drive
Field Replaceable Unit Disassembly/Assembly Hard drive Turn off the printer. Leave the power cord plugged in to provide a discharge path for static electricity. Remove the image processor board as detailed in the previous procedure, “Image processor board” on page 8-63. Disconnect the data cable and power wiring harness leading to the hard disk drive.
Page 243: Checks And Adjustments
Chapter Checks and Adjustments Required tools summary Magnetic tip screwdriver — 8.5 in. 003-0293-00 Extension tip 003-1388-00 Phaser 600 printer tool kit 650-3531-00 Torque-limiting screwdriver 003-0827-00 Drum alignment tool 003-1683-00 Ink loader alignment jig 003-1684-00 Lower roller guide alignment jig...
Page 244: Front Panel Menu
Print Quality Baud Rate Configuration Page Media Fusing Image Smoothing Data Bits Startup Page Media Cutting TekColor Correction Stop Bits Startup Page Parity SCSI Startup Mode Flow Control PS Error Handler Figure 9-1 Main menu map Phaser 600 Color Printer...
Page 245 Checks and Adjustments To access the Extended Service Support menu, scroll to the main menu item Service Support and then press the Menu and then the Exit buttons, release both buttons together. Pressing Menu alone allows you to access the printer copy counts and fault history. Network Settings Utilities Service Support...
Page 246: Printing Service Test Prints
Printheads that have been in operation for some amount of time inevitably undergo an aging effect with a slight loss of print quality; the adjustment “Adjusting for an aged printhead” on page 9-31. Phaser 600 Color Printer...
Page 247 Checks and Adjustments Printhead belt tension Turn off the printer. Open the top cover and remove the right cover. Ensure the printhead is in its home position. With a tension gauge with a wide-area tip (to not damage the belt), press down on the center of the top half of the X-axis belt until it contacts the lower-half of the X-axis belt.
Page 248 Fuser belt Press upper belt to 0.5 kg (1.1 lbs) when it contacts the fuser rail Adjust tension screws at the same time to center belt on pulley 9482-110 Figure 9-4 Setting fuser belt tension Phaser 600 Color Printer...
Page 249 Checks and Adjustments Y-axis motor belt and drum belt tension Turn off the printer. Open the top cover and remove the left cover. Loosen the screws securing the Y-axis motor. With a tension gauge, press down on the Y-axis motor belt tension with a pressure of 5 kgs (11 lbs.).
Page 250: Nvram Menu
Use the PC diagnostics to laterally adjust the position of the printhead when it is positioned in front of the maintenance station for a cleaning cycle. Refer to the diagnostic menu item Calibration — Engine NVRAM Menu. Phaser 600 Color Printer...
Page 251 Checks and Adjustments Lower roller guide alignment Turn off the printer. Remove the media roll and the roll cover. Remove the front cover plate located in front of the fuser. Open the fuser. Loosen the four alignment screws reached through the access holes through the fuser.
Page 252 Alignment screws Fuser through access holes through access holes Lower roller under fuser under fuser guide Alignment screws Lower Fuser Alignment front cover shims 9482-113 Figure 9-7 Aligning the lower roller guide to the fuser 9-10 Phaser 600 Color Printer...
Page 253 Checks and Adjustments Paper clamp alignment Either manually or using the PC diagnostics, rotate the paper clamp to its ready position. Inspect the paper clamp to ensure it is not bowed or bend and is parallel with the surface of the drum If necessary, loosen the three screws securing the clamp to the clamp side plate and adjust the clamp so has about a 3 mm (1/8 in) gap from the surface of the drum...
Page 254 Back tension blade Paper clamp Loosen 2 hex set screws Back tension blade Parallel at each end Paper clamp 9482-116 Figure 9-9 Aligning the paper clamp Tighten the set screws once the adjustment is correct. 9-12 Phaser 600 Color Printer...
Page 255 Checks and Adjustments Ink loader sensor ﬂag adjustment Inspect each sensor ﬂag, ensuring that it is in the proper position, prior to being actuated. The actuated portion of the ﬂags, when not actuated, should be perpendicular to the track of the ink sticks. Use a 1.5 mm hex wrench to adjust the ﬂag on its shaft.
Page 256 Set the value to match the offset on the rear of the printhead. Scroll to the Enh Head Temp Adjust menu’s sub-menu Enhanced mode temperature adjustment. Set the value to match the offset on the rear of the printhead. Exit the menu. 9-14 Phaser 600 Color Printer...
Page 257: Printhead Drive Voltage Adjustment
Checks and Adjustments Printhead drive voltage adjustment The voltage used to drive the printhead’s piezo-electric crystals is unique to each printhead. Each printhead’s required voltage is printed on the back of each printhead. Generally, once the voltage is set for a printhead, it is not changed. It may, in rare cases, be changed as the printhead ages.
Page 258 The printhead should move toward the drum. Head-to-media motor shaft Head-to-media assembly Drum Printhead Dimple Slide ramp Back tension blade Shim clip X-axis belt Figure 9-12 Positioning the printhead for the head-to-media adjustment 9-16 Phaser 600 Color Printer...
Page 259 Checks and Adjustments Attach the spring loader to the tailpiece. Tighten the three tailpiece screws to 3.5 in./lbs. (0.40 Nm) starting with the upper-right screw and proceeding clockwise. Remove the spring loader. Spring loader Tailpiece screws Tailpiece 9482-107 Figure 9-13 Adjusting the tailpiece Warning The printhead is hot.
Page 260 12. Install the tailpiece cover by hooking it on the top of the tailpiece and hinging it down to snap in place on the bottom of the tailpiece. Be careful to clear the torsion spring on the tailpiece. Proceed to the drum alignment adjustment. 9-18 Phaser 600 Color Printer...
Page 261 Checks and Adjustments Drum alignment Note This adjustment should only be made once the printhead voltage and tailpiece adjustments have been correctly set. Load ANSI E-size, ISO A0, Arch E or JIS B1 paper into the printer. Turn on the printer and allow the printer to reach its Ready state. Through the front panel menu, scroll to the Utilities menu and select the Test Print.
Page 262 Once the alignment is correct, tighten the bearing, reassemble the printer and make another test print. 10. Repeat the adjustment until it is correct. 9-20 Phaser 600 Color Printer...
Page 263 Checks and Adjustments Bi-directional print convergence Convergence is the key printhead “ﬁne-tuning” adjustment. Convergence sets the bidirectional printing alignment of the printer. Generally, you only make convergence adjustments to compensate for any printhead print quality changes that occur due to printhead aging. Convergence is an electronic adjustment; no mechanical adjustments are required.
Page 264 Check, clean and adjust, if necessary. Also try printing on thinner and thicker sheets of media to ensure the tailpiece performs correctly. 9-22 Phaser 600 Color Printer...
Page 265 Checks and Adjustments Enhanced Standard 1.75 Enhanced Standard Enhanced Standard 1.25 Enhanced Standard Enhanced Standard 0.75 Set adjust value to match pattern with Enhanced vertical center line Standard Enhanced Standard 0.25 Enhanced Standard Enhanced Standard -0.25 Enhanced Standard -0.5 Enhanced Standard -0.75 Enhanced...
Page 266: Tilt Adjustment
Retighten the right-side adjusting screw. Press Print to print another tilt adjustment pattern. Repeat Steps 6 and 7 until the black printing is level with the cyan printing. Exit to the main menu. Note Misalignment must not exceed pixel. 9-24 Phaser 600 Color Printer...
Page 267 Checks and Adjustments Adjust the printhead's Lube point position in the carriage Lube the contact area between the printhead and the carriage Test prints Black higher than Black lower than cyan cyan First loosen this screw . . . First loosen this screw ..
Page 268 Scroll back to Drum Step Pattern menu and print another test print to check the adjustment. If the alignment does not remain consistent, then the Y-axis belt tension may be incorrect. Check, clean and adjust, if necessary. 9-26 Phaser 600 Color Printer...
Page 269 Checks and Adjustments Step Adj. = 30 Step Adj. = 20 Step Adj. = 10 Step Adj. Overlap - drum step is too long Step Adj. = -10 Step Adj. = -20 Step Adj. = -30 Step Adj. (Present) Skip - drum step is too short 9482-79 Figure 9-17 Setting the drum step adjustment...
Page 270: Temperature Offset Adjustment
Since changing the printhead temperature alters the viscosity of the ink, its travel time from the jet nozzle to the paper is changed. Proceed to the convergence adjustment earlier in this procedure to ensure that bi-directional printing is correct. 9-28 Phaser 600 Color Printer...
Page 271 Checks and Adjustments Solid fills (pattern in this box is for head-test evaluation only) Uneven spacing Lines show a broken appearance. Good 8.5 kHz lines The printhead is too cold or the voltage is too low. Hooked ends Lines disrupted by "lane changing" and hooked ends that indicate the printhead is too hot or the voltage is too high.
Page 272: Sensor Calibration
Chapter 6 topic, “PC-based diagnostics” on page 6-26. Run the diagnostic test Calibrations — Sensor Calibration ... Load Cal Media. Load a hand-fed sheet of Phaser 600 Tektronix-brand translucent ﬁlm; use a pre-cut B-size sheet. The printer will advance the media into the print position.
Page 273: Adjusting For An Aged Printhead
Checks and Adjustments Adjusting for an aged printhead As a printhead ages, its print quality may change. It may not eject ink droplets with the same force as when it was new; the ﬂight-time of the ink droplets has decreased. This results in bidirectional mis-convergence. This can be adjusted for.
Page 274: Vacuum Check
In addition, you can determine if the maintenance station is sealing properly against the printhead faceplate. Turn off the printer and remove the power cord. Remove the top and right-side covers as explained in the Chapter 8 topic, “Printer cabinet” on page 8-2 . 9-32 Phaser 600 Color Printer...
Page 275 Checks and Adjustments With a T-connector, connect the vacuum gauge to the inlet side of the solenoid valve. This allows you to check the action of the vacuum pump and maintenance station seal. Maintenance Vacuum station gauge - 7 6 Air pump Filter T-connector...
Page 276: Resetting Nvram
NVRAM contents to their factory default values. Viewing NVRAM contents You can use the PC diagnostic’s NVRAM Test menu to select a test item that lets you view and change the contents of NVRAM. Figure 9-20 Viewing NVRAM contents 9-34 Phaser 600 Color Printer...
Page 277 Appendix Field Replaceable Units List This appendix provides a list of ﬁeld replaceable units for the Phaser 600 Color Printer. Changes to Tektronix products are made to accommodate improved components as they become available. It is important when ordering parts to...
Page 278 Cabinet: Paper Guide/Cover 650-3257-00 Front Panel LCD Board and Bezel 671-3638-00 Front Panel LCD Board 118-9399-00 Cabinet: Right Side Cover 118-9395-00 Casters Kit 118-9318-00 Roll Cover Spacer Pin Kit 118-9322-00 Cabinet: Roll Cover 118-9316-00 Output Bin Phaser 600 Color Printer...
Page 279 9482-83 Figure A-1 The printer exterior FRUs Service Manual...
Page 280 Heater Interconnect Board 650-3596-00 Head Carriage Bd. 118-9423-00 Spring Kit (1 Per Type Spring) 118-9287-00 Printhead Umbilical Cable 346-0265-00 Hi-temp Cable Ties For Head Wiring 118-9310-00 Timing Fence (Dot Clock) & Spring 118-9306-00 X-Axis Steel Belt Assy Phaser 600 Color Printer...
Page 281 FRU Replaceable Parts List 9482-84 Figure A-2 Printer interior FRUs Service Manual...
Page 282 Blank Cover Plate (no card installed) 213-1090-00 Blank Cover Plate Thumbscrews 671-3318-00 8 Mbyte RAM SIMM 671-3133-00 16 Mbyte RAM SIMM 671-3138-00 32 Mbyte RAM SIMM 671-3750-00 Image Processor Board 118-9421-00 Head Voltage Adjust Access Cover Phaser 600 Color Printer...
Page 283 FRU Replaceable Parts List 9482 85 Figure A-3 Printer electronics bay FRUs Service Manual...
Page 285: Wiring Diagrams
Appendix Wiring Diagrams Paper Edge Media Input Sensor Skew Sensor 1 Paper Edge Skew Sensor 4 Paper Edge Skew Sensor 3 Right Cover Black Motor Sersnor J502 J503 J505 Magenta Motor Left Cover Top Cover Junction Board Sensor Fuser Motor Y-Motor Yellow Motor Encoder...
Page 286 Wiring Diagrams The following illustrations detail the proper means of routing and dressing printer wiring. Incorrect wiring Power wiring, for motors and solenoids, is kept separate from signal wiring, for sensors, to minimize dressing can result in wires pinched by cabinet panels or damaged by moving parts of the printer. crosstalk.
