4-6.4 Advanced Chipset Features

• ADVANCED CHIPSET FEATURES is used to modify the values of
chipset buffers. These buffers control the system options.
Run the ADVANCED CHIPSET FEATURES as follows:
1. Choose "ADVANCED CHIPSET FEATURES" from the Main Menu and
a list of option will appear:
CMOS Setup Utility - Copyright (C) 1984 - 2001 Award Software
DRAM Timing Selectable
CAS Latency Time
Active to Precharge Delay
DRAM RAS# to CAS# Delay
DRAM RAS# Precharge
DRAM Data Intergrity Mode
Memory Frequency For
DRAM Read Thermal Mgmt
System BIOS Cacheable
Video BIOS Cacheable
Video RAM Cacheable
Memory Hole At 15M-16M
AGP Aperture Size(MB)
Delay Prior to Thermal
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
2. Use one of the arrow keys to move between options and modify the
selected options by using PgUp / PgDn / + / - keys. An explanation of
the <F> keys follows:
<F1>: "Help" gives options available for each item.
<F5>: Get the previous values. These values are the values with which
the user starts the current session.
<F6>: Load all options with the BIOS default values.
<F7>: Load all options with the Setup default values.
Advanced Chipset Features
1.5
7
3
3
Non-ECC
Disabled
Disabled
Disabled
Disabled
Disabled
64
16 Min
57
