2-4 AGP 4X (Accelerated Graphics Port) Installation

Warning:
• The AGP 4X slot on board supports solely 4X AGP card configuration.
User should not insert 1X / 2X AGP card to this mainboard.
• LED2 AGP Protection Indicator is on board this series. In case inappropriate
AGP card (such as AGP 2X) is inserted into this AGP 4X Slot, LED2 will
light up to warn that AGP installation is inproper. The wrong AGP card
should be replaced; otherwise system cannot be booted.
mPGA478B
Clock
Generator
1
Intel RG82845
1 3
LED2
FAN2
AC'97
Codec CD1
1 4
1 4
CD2
1 3 WOL1
SW1
AGP Accelerator
4X notch
AGP4X
1 3
FAN1
1
Intel RG82845
IDE1
Li
Battery
PCI 1
AGP4X
PCI 2
82801BA
PCI 3
USB1
FWH
DIP
1 3
16
1
1 2 3 4 5
FAN3
19
Chapter 2 Hardware Setup
Card Latch
LED2
AGP Protection Indicator
