4-6 BIOS Setup --- CMOS Setup Utility

4-6.1 CMOS Setup Utility

• This mainboard comes with the AWARD BIOS from AWARD Software
Inc. Enter the CMOS Setup Utility Main Menu by:
1. Turn on or reboot your system. After a series of diagnostic checks, the
following message will appear:
2. Press the <DEL> key and the main program screen will appear as
follows.
CMOS Setup Utility - Copyright (C)
Standard CMOS Features
Advanced BIOS Features
Advanced Chipset Features
Integrated Peripherals
Power Management Setup
PnP/PCI Configurations
SmartDoc Anti-Burn Shield
Esc : Quit
F10 : Save & Exit Setup
3. Use the arrow keys on your keyboard to select an option, and press
<Enter>. Modify the system parameters to reflect the options installed
in your system.
4. You may return to the Main Menu anytime by pressing <ESC>.
5. In the Main Menu, "SAVE AND EXIT SETUP" saves your changes and
reboots the system, and "EXIT WITHOUT SAVING" ignores your chan-
ges and exits the program.
PRESS <DEL> TO ENTER SETUP
Time, Date, Hard Disk Type...
49
Chapter 4 BIOS Setup
1984 - 2001 Award Software
Frequency/Voltage Control
Load Optimized Defaults
Set Supervisor Password
Set User Password
SAVE & EXIT SETUP
EXIT WITHOUT SAVING
: Select Item
