1. SMI Connector (System Management Interrupt):
CONNECTION: This 2-pin connector is connected to the case-mounted
FUNCTION
: Manually placing the system into a Suspend mode or
2. Power Switch Connector:
CONNECTION: Connected to a momentary button or switch.
FUNCTION
: Manually switching the system between "On" and "Soft
3. IR Connector (Infrared Connector):
CONNECTION: Connected to Connector IR on board.
FUNCTION
: Supporting wireless transmitting and receiving module
4. 1st HDD LED Connector / 2nd HDD LED Connector:
CONNECTION: Connected to HDD LED.
FUNCTION
: To supply power to HDD LED.
5. Suspend LED Connector:
CONNECTION: Connected to Suspend indicator.
FUNCTION
: To supply power to "Suspend indicator".
6. Keylock Connector:
CONNECTION: Connected to keylock switch.
FUNCTION
: To lock keyboard for security purpose.
7. Power LED Connector:
CONNECTION: Connected to System Power LED.
FUNCTION
: To supply power to "System Power LED".
8. Reset Switch Connector:
CONNECTION: Connected to the case-mounted "Reset Switch".
FUNCTION
: To supply power to "Reset Switch" and support
9. Speaker Connector:
CONNECTION: Connected to the case-mounted Speaker.
FUNCTION
: To supply power to the case-mounted Speaker.
Suspend Switch.
"Green" mode.
Off". Pressing the momentary button for more than 4
seconds will also turn the system off.
on board.
system reboot function.
29
Chapter 2 Hardware Setup
