SOLTEK SL-85SID User Manual page 73

2. Use one of the arrow keys to move between options and modify the
selected options by using PgUp / PgDn / + / - keys.
<F1>: "Help" gives options available for each item.
<F5>: Get the previous values. These values are the values with which
the user starts the current session.
<F6>: Load all options with the BIOS default values.
<F7>: Load all options with the Setup default values.
3. Press <ESC> to return to the Main Menu when you finish setting up all
items. please read the following explanatory information for your
SmartDoc Anti-Burn Shield Configuration:
CPU Warning Tem-
perature
Current CPU1/2 Temp. Showing the working CPU temperature.
Current System Temp. Showing the working System temperature.
CPUFAN1/2/3 Speed Showing the working CPU Fan speed.
IN0/1/2, +5V/+12V/-
12V/-5V
VBAT Showing the working battery voltage on board.
5VSB Showing the working standby voltage on board.
This field allows you to select a CPU Warning
temperature against the CPU over heat. If the CPU
temperature reaches "CPU warning temperature"
that you select in this field, the BIOS will send out a
warning message.
Showing the working voltage on board.
73
Chapter 4 BIOS Setup
