SOLTEK SL-85SID User Manual page 64

85SID
RxD, TxD Active This item allows you to select the correct setting
of the Receive Data and Transmit Data signals
for your IR peripherals.
The choices: Hi,Lo (default); Lo, Hi; Lo, Lo; Hi, Hi.
IR Transmission delay This item allows you to Enable/Disable the Ir
Transmission Delay.
The choices: Enabled (default); Disabled.
UR2 Duplex Mode This item allows you to select the IR half / full
duplex function.
The choices: Half; Full.
Use IR Pins To select the correct setting of RxD, TxD signals
of your IR peripherals. You may also refer to your
IR peripherals document for the correct setting.
The choices: IR-Rx2Tx2 (default); RxD2, TxD2;
Onboard Parallel Port This item allows you to determine onboard parallel
port controller I/O address setting.
The choices: 378H/IRQ7; 278H/IRQ5; 3BC/IRQ7;
Disabled.
Parallel Port Mode Select an operating mode for the on-board parallel
(printer) port. Select Normal, Compatible, or SPP
unless you are certain your hardware and software
both support one of the other available modes.
EPP Mode Select Select a mode of data transfer of the Enhanced
Parallel port for your parallel devices.
Choices: EPP1.7(default); EPP1.9;
ECP Mode Use DMA Select a DMA channel for the Enhanced Communi-
cation port. Choices: 3 (default); 1.
64
