Page 1 D-Link™ DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual V1.00...
Page 2 Reproduction in any manner whatsoever without the written permission of D-Link Computer Corporation is strictly forbidden. Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Computer Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation.
Page 3: Table Of Contents
DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual Table of Contents INTRODUCTION ..............................1 USING THE CONSOLE CLI.............................4 COMMAND SYNTAX ...............................8 BASIC SWITCH COMMANDS..........................11 create account..................................12 config account..................................12 show account..................................12 show session..................................13 show switch..................................14 show serial_port .................................. 14 config serial_port ................................
Page 4 DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual show snmp engineID................................35 create snmp group ................................35 delete snmp group ................................37 show snmp groups................................37 create snmp host.................................. 39 delete snmp host.................................. 40 show snmp host................................... 40 create trusted_host................................41 show trusted_host................................
Page 5 DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual config stp mst_config_id..............................67 config stp mst_ports ................................68 FORWARDING DATABASE COMMANDS......................70 create fdb..................................... 70 create multicast_fdb ................................71 config multicast_fdb ................................71 config fdb aging_time ................................. 72 delete fdb..................................... 72 clear fdb ....................................73 show multicast_fdb ................................
Page 6 DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual config igmp_snooping................................. 98 config router_port ................................99 enable igmp_snooping ................................ 99 disable igmp_snooping ..............................100 show igmp_snooping ................................ 100 show igmp_snooping group .............................. 101 show igmp_snooping forwarding............................101 show router_port ................................102 802.1X COMMANDS............................103...
Page 7 DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual clear arptable..................................126 COMMAND HISTORY LIST COMMANDS ......................127 ?......................................127 show command_history ..............................128 dir ...................................... 128 config command_history..............................129 SSH COMMANDS..............................130 enable ssh ..................................130 disable ssh ..................................131 config ssh authmode................................131 show ssh authmode ................................
Page 8 DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual STACKING COMMANDS ............................157 config box_id ..................................157 show stack_information ..............................157 POE COMMANDS..............................159 config poe..................................159 config poe ports................................. 160 show poe ................................... 160 ACCESS CONTROL LIST COMMANDS ......................162 create access_profile (Ethernet) ............................162 create access_profile (IP) ..............................
Page 9: Introduction
NTRODUCTION The DGS-3100 is a member of the D-Link DGS-3100 switch family. The DGS 3100 product range consists of 24 / 48 -port 10/100/1000Base-T PoE / NonPoE L2 Stackable Management Switches with 4 Combo SFPs. The Switch can be managed through the Switch’s serial port, Telnet, or the Web-based management agent. The Command Line Interface (CLI) can be used to configure and manage the Switch via the serial port or Telnet interfaces.
Page 10 DGS-3100 Gigabit Ethernet Switch Manual Figure 1–2. Boot Screen The Switch’s MAC address can also be found in the Web management program on the Device Information window on the Configuration menu. The IP address for the Switch must be set before it can be managed with the Web-based manager. The Switch IP address can be automatically set using BOOTP or DHCP protocols, in which case the actual address assigned to the Switch must be known.
Page 11 Telnet, SNMP MIB browser and the CLI or via the Web-based manage ment agent using the above IP address to connect to the Switch. NOTE: The DGS-3100 series of switches have the pability to be config d for an IP addre of 0.0.0.0, or, in essence, have no IP address. Th is function maybe used to disable Layer 3 functions of the Switch.
Page 12: Using The Console Cli
DGS-3100 Gigabit Ethernet Switch Manual SING THE ONSOLE The Switch supports a console management interface that allows the user to connect to the Switch’s management agent via a serial port and a terminal or a computer running a terminal emulation program. The console can also be used over the network using the TCP/IP Telnet protocol.
Page 13 Commands are entered at the command prompt, DGS3100#. There are a number of helpful features included in the CLI. Entering the ? c ommand will display a list of all of the top-level commands. Figure 2–2. The ? Command When entering a comma nd without its required parameters, the CLI displays the p rompt: command: config account message and the options listed below.
Page 14 DGS-3100 Gigabit Ethernet Switch Manual Figure 2–4. Using the Up Arrow to Re-enter a Command In the above example, the command config account was entered without the required pa rameter <username>, the CLI returned the command: config account prompt. The up arrow cursor contro l key was pressed to re-enter the previou s command (...
Page 15 Figure 2–6. Next possible completions: Show Command In the above example, all of the possible next para meters for the show command are displayed. At the next command prompt in the example, the up arro w was used to re-enter the show command, followed by the account parameter.
Page 16: Command Syntax
DGS-3100 Gigabit Ethernet Switch Manual OMMAND YNTAX The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI and available through the console interface uses the same syntax.
Page 17 {braces} Purpose Encloses an optional value or set of optional arguments. Syntax reset {[config | system]} Description In the above syntax example, users have the option to specify config or system. It is not ne cessary to specify either optional value, however the effect of the system reset is dependent on which, if any, value is specified.
Page 18 DGS-3100 Gigabit Ethernet Switch Manual Stop s the display of remaining pages when multiple pages are to be disp layed. freshes the pages currentl y displayed. Displays the remaining pages without pausing between pages. Enter Displays the next line or table entry.
Page 19: Basic Switch Commands
ASIC WITCH OMMANDS The Basic S witch comma nds in the Com mand Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create account [admin | user] <username 15> config account <username 15> show account show session show switch...
Page 20: Create Account
DGS-3100 Gigabit Ethernet Switch Manual create account Purpose To create user accounts. Syntax create account [admin | user] <username 15> The create account command creates an administrator or user Description account that consists of a username and an optional password. Up to 31 accounts can be created.
Page 21: Show Session
Syntax show account Description The show acc ount command displays all account usernames and their access levels created on the Switch. Up to 31 user accounts can exist on the Switch at one time. Parameters None. Restrictions None. Example usage: To display the accounts that have been created: DGS3100# show account Username...
Page 22: Show Switch
DGS-3100 Gigabit Ethernet Switch Manual show switch Purpose To display information about the Switch. Syntax show switch Description The show switch command displays information about the Switch settings, including Device Type, MAC Address, IP configurat ion, Hardware/Software version, System information, and Sw itch Network configuratio Parameters...
Page 23: Config Serial_Port
Baud Rate : 9600 ata Bits Parity Bits : None top Bits Auto-Logou : 10 mins DGS3100# config serial_port Purpose To configure the serial port. Syntax config serial_port {baud_rate [9600 | 19200 | 38400] auto_logout [never | 2_minutes | 5_minutes| 10_minutes | 15_minutes]} Description The show serial_port command configures the serial port’s baud...
Page 24: Disable Clipaging
DGS-3100 Gigabit Ethernet Switch Manual would display more than one screen of information. The default setting is enabled. Parameters None. Restrictions Only dministrator-level users can issue this command. Example usa To enable pausing of the scree n display when the show command output reaches the end of the page: DGS3 # enabl e clipaging...
Page 25: Enable Web
re you sure to delete the last administrator account?(y/n) Success. DGS3100# enable web Purpose To enable the HTTP-based management software on the Switch. Syntax enable web <tcp_port_number 1-65535> Description The enable web command enables the Web-based management software on the Switch. The user can specify the TCP port number the Swi tch will use to listen for Telnet requests.
Page 26: Save
DGS-3100 Gigabit Ethernet Switch Manual save Purpose To save changes in the Switch’s configuration to non-volatile RAM. Syntax save Description The save command saves the current switch configuration to non- volatile RAM. The saved switch configuration will be loaded into the Switch’s memory each time the Switch is restarted.
Page 27: Login
DGS3100# reset Are you sure to p roceed with system reset?(y/n) Success. DGS3100 login Purpose To log in a user to the Switch’s console. Syntax login Description The login command initiates the login procedure. The user is prompted for the Username and Password. Parameters None.
Page 28: Show Cpu Utilization
DGS-3100 Gigabit Ethernet Switch Manual Parameters <ipaddr> - The IP address of the host. times <value 1-255> - The number of individual ICMP echo messages to be sent. The maximum value is 255. The default is 0. Pinging an IP address without the times parameter will ping the target device an infinite number of times.
Page 29: Show Configuration
show configuration Purpose To display the current or saved version of the configuration settings of the Sw itch. Syntax show configuration [running | startup] Description The show configuration command displays the current or saved rsion of the configuration settings of the Switch. Parameters running –...
Page 30: Disable Jumbo_Frame
DGS-3100 Gigabit Ethernet Switch Manual disable jumbo_frame Purpose To disable jumbo frames on the device. Syntax disable jumbo_frame Description The disable jumbo_frame command disables jumbo frames on the device. Parameters None. Restrictions None. ample usage: To disable jumbo_fram S3100# disa ble jumbo_frame Su cess.
Page 31 Parameters None. Restrictions None. Example usage: To display the curren tly active switch DGS3100# l ocate Success. DGS3 100#...
Page 32: Switch Port Commands
DGS-3100 Gigabit Ethernet Switch Manual WITCH MMANDS The Switch Port comma nds in th e Command Line Interface (CLI) are listed (along with the appro priate parameters) in the following table. Command Parameter [all | < portlist> ] {speed [auto | 10_half | 10_full | 100_half | 100_full | 1000_full] | config ports flow_control [enable | disable | auto] | learning [enable | disable] | state [enable | disable...
Page 33: Show Ports
To configure the speed of ports 1-3 to be 10 Mbps, full duplex, learning and state enabled: DGS3100# config ports 1-3 speed 10_full learning enable s tate enable Success. DGS3100# show ports Purpose To display the current configuration of a range of ports. Syntax show ports {<portlist>} Description...
Page 34: Config Ports Description
DGS-3100 Gigabit Ethernet Switch Manual config ports description Purpose To add a description to an interface or ranges of interface. Syntax config por description <portlist> <s tring 1-64> Description The config ports description command adds a description to an interface or a range of interfaces. Parameters <portlist>...
Page 35 To display the description of port 1: DGS3100# show ports description 1:1 Port Description ----- ------ ----------------- For testing purposes only S3100#...
Page 36: Network Management (Snmp) Commands
DGS-3100 Gigabit Ethernet Switch Manual (SNMP) ETWORK NAGEMENT OMMANDS The Network Management commands in the Comm and Line Interface (CLI) are listed (along with the appr opriate parameters) in the following table. Command Parameter <username 24> <groupname 30> [encrypted [by_password auth [md5 create snmp user <auth_password 1-32>...
Page 37: Create Snmp User
Command Parameter disable snmp authenticate trap show snmp traps config snmp <sw_contact> system_contact config snmp <sw_location> system_location config snmp <sw_nam e> system_name Each command is listed in detail, as follows: create snmp user Purpose To create a new SNMP user and add the user to an SNMP group. Syntax create snm p user <username 24>...
Page 38: Delete Snmp User
DGS-3100 Gigabit Ethernet Switch Manual level will be used. • <auth password 1-32> - A string of between 1 and 32 alphanumeric characters used to authorize the agent to receive packets for the host. • <auth_key 40 or 72> - A string of exac tly 40 or 72 alphanumeric characters, in hex form, to define the key used to authorize the agent to receive packets...
Page 39: Create Snmp View
xample usage: To di splay the SNMP users currently configured on the Switch: DGS3100# show snmp user Username Group Name SNMP Version Auth-Protocol ------------- -- --------------- ------------ ------------- Initial initial None Total Ent ries: 1 DGS3100 create snmp view Purpose To assign views to community string s to limit which MIB objects an SNMP manager can access.
Page 40: Show Snmp View
DGS-3100 Gigabit Ethernet Switch Manual all − Specifies that all of the SNMP views on the Switch will be deleted. <oid> − The object ID that identifies an object tree (MIB tree ) that will be deleted from the Switch. Restrictions Only administrator-level users can issue this command.
Page 41: Create Snmp Community
create snmp community Purpose To create an SNMP community string to define the relationship between the SNMP manager and an SNMP agent. Syntax create snmp community <community_string 20> view <view_name 30> [read_only | read_write] Description The create snmp community command creates an SNMP community string and assigns a ccess-limiting characteristics to this community string.
Page 42: Show Snmp Community
DGS-3100 Gigabit Ethernet Switch Manual characters that is used to identify members of an SNMP community to delete. This string is used like a password to give remote SNMP managers access to MIB objects in the Switch’s SNMP agent. Restrictions Only administrator-level users can issue this command.
Page 43: Show Snmp Engineid
SNMP engine on the Switch. Parameters − defines the automatically created engineID based on the default device ma <snmp_engineID 10-64> − A string, of between 10 and 64 alphanumeric characters, to be used to identify the SNMP engine on the Switch. Restrictions Only administrator-level users can issue this command.
Page 44 DGS-3100 Gigabit Ethernet Switch Manual Network Management Pr otocol (SNMP), version 1, is a network management protocol th at provides a means to monitor and control network devices. v2c – Specifies that SNMP version 2c is to be used. The SNMP v2c supports both centralized and distributed network management strategies.
Page 45: Delete Snmp Group
delete snmp group Purpose To remove an SNMP group fr om the Switch. Syntax delete snmp group <groupname 30> Description The delete snmp group command removes an SNMP group from the Switch. Parameters <groupname 30> − A string of u p to 30 alphanumeric characters that identifies the SNMP group the new SNMP user will be associated...
Page 46 DGS-3100 Gigabit Ethernet Switch Manual Notify Vie w Name : NotifyView Security Model : SNMPv3 Security Level : authNoPriv Group Na : Group5 ReadView Name : ReadView WriteView Name : WriteVie Notify Vie w Name : NotifyView Security Model : SNMPv3 Security Level : authNoPriv...
Page 47: Create Snmp Host
WriteView Name : Co mmunityView Noti fy Vie w Name : CommunityView Security Model : SNMPv1 Securit Level : NoAuthNoPriv Group Name : WriteGroup ReadView Name : CommunityView WriteView Name : Commu nityView otify View Name : CommunityView Security Model : SNMPv2 Security Level : NoAuthNoPriv...
Page 48: Delete Snmp Host
DGS-3100 Gigabit Ethernet Switch Manual encryption of packets sent between the Switch and a remote SNMP manager. priv − Specifies that authorization is required, but there is no auth_no encryption of packets sent between the Switch and a remote SNMP manager.
Page 49: Create Trusted_Host
SNMP agent. Parameters <ipaddr> − The IP address of a remote SNMP manager that receives SNMP traps g enerated by the Switch’s SNMP agent. Restrictions None. Example usage: To display the curr ently configur ed SNMP hosts on the Switch: DGS3100# show snmp host SNMP Host Table Host IP A...
Page 50: Delete Trusted_Host
DGS-3100 Gigabit Ethernet Switch Manual Description The show trusted_host command displays a list of trusted hosts entered on the Switch using the create trusted_host command above. Parameters <ipaddr> − The IP address of the trusted host. Restrictions None. Exampl e usage: To display the list of trusted hosts: GS3100# show trusted_host...
Page 51: Disable Snmp Traps
Example usage: To enable SNMP tr p support on the Switch: DGS3100# enable snmp traps Success. DGS3100# disable snmp traps Purpose To disable SNMP trap support on the Switch. Syntax disable snmp traps Description The disable snmp traps command disables SNMP trap support on the Sw itch.
Page 52: Show Snmp Traps
DGS-3100 Gigabit Ethernet Switch Manual Description The disable snmp authenticate trap command disables SN authentication trap support on the Switch. Parameters None. Restrictions Only administrator-level users can issue this command. Example usage: To disable the SNMP authentication trap support: DGS3100# disable snmp authenticate trap Success.
Page 53: Config Snmp System_Location
DGS3100# config snmp system_contact MIS Department II Success. DGS3100# config snmp system_location Purpose To enter a description of the location of the Switch. Syntax config snmp system_location <sw_location> Description The config snmp system_location command enters a description of the location of the Switch. A maximum of 255 characters can be used.
Page 54: Download/Upload Commands
DGS-3100 Gigabit Ethernet Switch Manual OWNLOAD PLOAD OMMANDS The Download/Upload commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter [firmware <ipaddr> <path_filename 64> | boot <ipaddr> <path_filename 64> | download configuratio n <ipaddr>...
Page 55: Upload
!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!! !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!01–Jan–2000 01:22:49 %COPY–W–TRAP: The copy o peration was completed successfully 3920460 by tes copied in 00:03:01 [hh:mm:ss DGS3100# upload Purpose To upload the current sw itch settings to a TFTP server. Syntax upload configuration <ipaddr>...
Page 56: Network Monitoring Commands
DGS-3100 Gigabit Ethernet Switch Manual ONITORING OMMANDS The Network Monitoring command s in the Command Line I nterface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter show packet ports <portlist> show error ports <portlist> show utilization clear counters clear log...
Page 57: Show Error Ports
Exampl e usage: To display the pack ets analysis for port 7: GS3100# show packet ports 7 Port numb er : 7 rame Size Frame Counts Frames/sec Frame Type Total Total/sec ------------------ -------------------- ---------------- ----------------- ------- ------------- 3275 RX Bytes 408973 1657 65-127 RX Frames...
Page 58: Show Utilization
DGS-3100 Gigabit Ethernet Switch Manual show utilization Purpose To display real-time port utilization statistics. Syntax show utilization Description The show utilization command displays the real-time port utilization statistics for the Switch. Parameters None. Restrictions None. Examp le usage: To display the port utilization statistics: DGS3100# show utilization Port TX/sec...
Page 59: Clear Log
To clear the counters: DGS3100# clear counters Succes DGS3100 clear log Purpose To clear the Switch’s history log. Syntax clear log Description The clear log co mmand clears the Switch’s history log. Parameters None. Restrictions Only administrator-level u sers can issue this command. Example usage: To clear the log inf ormation:...
Page 60: Enable Syslog
DGS-3100 Gigabit Ethernet Switch Manual ver console , source 0.0.0. destination 0.0.0.0 TERMINATED. The Telnet/SSH se ssion may still be connect 03-Jan-2000 17:26:24 %COP -W-TRAP: The copy operation was completed succe ssfully 03-Jan-2000 17:26:17 %COPY-I-FILECPY: Files Copy - source URL running-con fig destination URL flash:/ /startup-config 03-Jan-2000 17:25:40...
Page 61: Show Syslog
show syslog Purpose To display the syslog protocol status. Syntax show syslog Description The show syslog command displays the syslog status (enabled disabled). Parameters None. Restrictions None. Example usage: To display the current status o f the syslog function: DGS3 # show syslog log Global State: Enabled DGS3100#...
Page 62 DGS-3100 Gigabit Ethernet Switch Manual informational − Specifies that informational mes sages are to be sent to the remote host. This corresponds to number 6 from the list above. warning − Specifies that warning messages a re to be sent to the remote host.
Page 63: Config Syslog Host
local3 − Specifies that local use 3 messages are to be sent to the remote host. This corresponds to number 19 from the list above. local4 − Specifies that local use 4 messages are to be sent to the remote host. This corresponds to number 20 from the list above. local5 −...
Page 64 DGS-3100 Gigabit Ethernet Switch Manual Error: error conditions Warning: warning conditions Notice: normal but significant condition Informational: informational messages Debug: debug-level messages informational − Specifies that informational messages are to be sent to the remote host. This corresponds to number 6 from the list above.
Page 65: Delete Syslog Host
remote host. This corresponds to number 16 from the list above. local1 − Specifies that local use 1 messages are to be sent to remote host. This corresponds to number 17 from the list above. local2 − Specifies tha t local use 2 messages are to be sent to the remote host.
Page 66: Show Syslog Host
DGS-3100 Gigabit Ethernet Switch Manual show syslog host Purpose To display the syslog hosts currently configured on the Switch. Syntax show syslog host {<index 1-4>} Description The show syslog host command displays the syslog hosts that are currently configured on the Switch. Parameters <index 1-4>...
Page 67: Spanning Tree Commands
PANNING OMMANDS The Spanning Tree commands in the Co mmand Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter {maxa ge <value 6-40> | maxhops <value 1-20> | hellotime <value 1-10> | config stp forwar ddelay <value 4-30>| fbpdu [enable | disable]} <portl...
Page 68: Config Stp Ports
DGS-3100 Gigabit Ethernet Switch Manual will start sending its own BPDU to all other switches for permission to become t he Root Bridge. If it turns out that your switch has the lowest Bridge Identifier, it will become the Root Bridge. The user may choose a time between 6 and 40 seconds.
Page 69: Config Stp Version
externalCost − Defines a metric that indicates the relative cost of forwarding packets to the specified port list. Port cost can be set automatically or as a metric value. The default value is auto. • auto – Automatically sets the speed for fo rwarding packets to the specif ied port(s) in the list for optimal efficien...
Page 70: Enable Stp
DGS-3100 Gigabit Ethernet Switch Manual rstp – Sets the Ra pid Spanning Tree Protocol (RSTP) globally on the Switch. stp – Sets the Spa nning Tree Protocol (STP) globally on the Switch. Restrictions Only administrator-level u sers can issue this command. Example usage: To set the Switch g lobally for the Mu...
Page 71: Show Stp
show stp Purpose To display the Switch’s current STP configuration. Syntax show stp Description The show stp command displays the Switch’s current STP configuration. Parameters None. Restrictions None. Example usage: To display the statu s of STP on the Switch: Status 1: STP ena bled with STP compatible version DGS3100# show stp...
Page 72: Show Stp Ports
DGS-3100 Gigabit Ethernet Switch Manual Forward Dela : 15 ax Age : 20 TX Hold Co Forwarding BPDU : Enabled DGS3100# show stp ports Purpose To display the Switch’s current instance_id configuration. Syntax show stp ports <portlist>} Description The show stp ports command displays the STP Instance Settings and STP Instance Operational Status currently implemented on the Switch.
Page 73: Show Stp Mst_Config_Id
the S witch. The value may be between 0 and 15. An entry of 0 displa ys the STP configuration for the CIST internally set on the Switch. Restrictions None. Example usa To display the STP instance c onfiguration for instance 0 (the internal CIST) on the Switch: DGS3100 # show stp instance 0 Instance...
Page 74: Config Stp Instance_Id
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# config stp instance_id Purpose To add or delete an STP instance ID. Syntax config stp instance_id <value 1-15> [add_vlan | remove_vlan] <vidlist> Description The config stp instance_id command maps VIDs (VLAN I Ds) to previously configured STP instances on the Switch by creating an instance_id.
Page 75: Config Stp Priority
config stp priority Purpose update the STP instance configuration. Syntax config stp priority <value 0-61440> instance_id <value 0-15> Description The config stp priority command updates the STP instance configuration settings on the Switch. The MSTP uses the priority in selecting the root bridge, root port and designated port. Assigning higher priorities to STP regions instructs the Switch to give precedence to the selected instance_id for forwarding packets.
Page 76: Config Stp Mst_Ports
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# config stp mst_config_id revision_level 10 name Trinity Success. DGS3100# config stp mst_ports Purpose To update the port configuration for a M STP instance. Syntax config stp mst_ports < p ortlist> instance_id <value 0-15> {internalCost [auto | va lue 1-200000000] | priority <value 0-240>} Description The config stp mst_ports command updates...
Page 77 Success. DGS3100...
Page 78: Forwarding Database Commands
DGS-3100 Gigabit Ethernet Switch Manual ORWARDI ATABASE OMMANDS The Forwardi ng Data base comman ds in the Command Line Interface (CLI) a re listed (along with the appropriate parameters) in the following table. Command Parameter create fdb <vlan_name 32> <macaddr> port <port> create multicast_fdb <vlan_name 32>...
Page 79: Create Multicast_Fdb
create multicast_fdb Purpose To create a static entry in the multicast MAC address forwarding table (database). Syntax create multicast_fdb <vlan_name 32> <macaddr> Description The create multi cast_fdb command creates a static entry in the multicast MAC address forwarding table (database). Parameters <vlan_name 32>...
Page 80: Config Fdb Aging_Time
DGS-3100 Gigabit Ethernet Switch Manual config fdb aging_time Purpose To set the aging time of the forwarding database. Syntax config fdb aging_time <value 10-6 30> Description The config fdb aging_time command sets the aging time of the forwarding database. The aging time affects the learning process of the Switch.
Page 81: Clear Fdb
clear fdb Purpose clear the Switch’s forwarding database of all dynamically learned C addresses. Syntax clear fdb all Description The clear fdb command clears dynamically learned entries from the Switch’s forwarding database. Parameters all − Clears all dynamic entries in the Switch’s forwarding database. Restrictions Only administrator-level users can issue this command.
Page 82: Show Fdb
DGS-3100 Gigabit Ethernet Switch Manual show fdb Purpose To display the current unicast MAC address forwarding database. Syntax show fdb {port <port> | vlan <vlan_name 32> | mac_address <macaddr> | static | aging_time} Description The show fdb command displays the current contents of the Switch’s forwarding database.
Page 83 DGS3100# show fdb aging_time Unicast MA C Address Aging Time = 5 DGS3100#...
Page 84: Broadcast Storm Control Commands
DGS-3100 Gigabit Ethernet Switch Manual ROADCAST TORM ONTROL OMMANDS The Broadcast Storm Control commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter {[<portlist> | all] state [enable | disable] | sto rm_type [broadcast | config traffic control broa...
Page 85: Show Traffic Control
Success. DGS3100# show traffic control Purpose To display current traffic control settings. Syntax show traffic control {ports <portlist>} Description The show traffic control command displays the current storm traffic control configuration on the Switch. Parameters ports <portlist> - A port or range of ports whose settings are to be displayed.
Page 86: Qos Commands
DGS-3100 Gigabit Ethernet Switch Manual OMMANDS The QoS commands in t he Command Line Interface (CLI) are listed (along with the appropriate parameters) in e following table. Command Parameter config sch eduling <class _id 0-3> max_packet <value 1-15> show scheduling config 802 <prior ity 0-7>...
Page 87: Show Scheduling
received. The max_packets parameter allows the user to specify the maximum number of packets a given hardware priority queue can transmit before allowing the next lowest hardware priority queue to begin transmitting its packets. A value between 1 and 15 can be specifie d.
Page 88: Config 802.1P User_Priority
DGS-3100 Gigabit Ethernet Switch Manual Class-0 Class-1 Class-2 Class-3 DGS3100 config 802.1p user_priority Purpose To map the 802.1p user priority of an incoming packet to one of the four hard ware classes of service available on the Switch. Syntax config 802.1p user_priority <priority 0-7> <class_id 0-3> Description The config 802.1p user_priority command configures the way the Switch maps an incoming packe...
Page 89: Config 802.1P Default_Priority
Syntax show 802.1p user_priority Description The show 802.1p user_priority command displays the current mapping of an incoming packet’s 802.1p priority value to one of the Switch’s four hardware priority queues. Parameters None. Restrictions None. Example usage: To show 802.1p user priority: DGS3100 # show 802.1p user_priority QOS Clas...
Page 90: Show 802.1P Default_Priority
DGS-3100 Gigabit Ethernet Switch Manual show 802.1p default_priority Purpose To display the cu rrently configured 802.1p priority value that is assigned t o an inco ming, untagged packet before being forwarded to its destina tion. Syntax show 802 .1p default_priority {<portlist>} Description 802.1p default_priority command displays the currently show...
Page 91: Show Scheduling_Mechanism
Description The co nfig scheduling_mechanism command configures the scheduling mechanism for the QoS function. It allows the user to select between a round robin (WRR) and a strict mechanism for emptying the priority classes of service of the QoS function. The Switch contains four h ardware priority classes of service.
Page 92: Config Rate_Limit
DGS-3100 Gigabit Ethernet Switch Manual QOS scheduling_mechanism CLASS ID Mechanism -------------- ------------------- Class-0 strict Class-1 strict Class-2 strict Class-3 strict ss-4 strict Class-5 strict ss-6 strict ss-7 strict DGS3100# config rate_limit Purpose To enable rate limitation of specific egress ports. Syntax config rate_limit [<portlist>...
Page 93 Restrictions None. Example usa To sh ow a port ’s rate limit: DGS3100# sho w rate_limit all Current rate limit Port te Limit ---- ----- ---------- 3500 3500 3500 3500 3500 3500 3500 3500 3500 3500 3500 RL+C ESC q Quit SPACE n Next Page ENTER Next Entry a ALL...
Page 94: Port Mirroring Commands
DGS-3100 Gigabit Ethernet Switch Manual IRRORING OMMANDS The Port Mirroring commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter config mirror target <port> source <port> direction [ing ress | egress | both] delete mirror target <port>...
Page 95: Delete Mirror
delete mirror Purpose To remove a previously entered port mirroring configuration. Syntax delete mirror target <port> source <port> Description The delete mirror command removes a previously configured mirror port − source port pair on the Switch. Parameters target <port> − Specifies the port that mirrors traffic forwarding. source <port>...
Page 96: Vlan Commands
DGS-3100 Gigabit Ethernet Switch Manual VLAN C MANDS The VLAN commands in the Comm and Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create vla <vlan_ name 32> {tag <vlanid 2-4094>} delete vlan <vlan_name 32>...
Page 97: Delete Vlan
delete vlan Purpose To delete a previously configured VLAN on the Switch. Syntax delete vlan vlan_name 32> Description The delete vlan command deletes a previously configured VLAN on the Switch. Parameters <vlan_name 32> − The name of the VLAN to be deleted. Restrictions Only administrator-level users can issue this command.
Page 98: Config Gvrp
DGS-3100 Gigabit Ethernet Switch Manual config gvrp Purpose To configure GVRP on the Switch. Syntax config gvrp [<portlist> | <ch1-32> | all] { ingress_checking [enable | disable] | acceptable_frame [tagged_only | admit_all] | pvid <vlanid 1-4094>} Description The config gvrp command configures the Group VLAN Registration Protocol on the Switch.
Page 99: Disable Gvrp
disable gvrp Purpose To disable GVRP on the Switch. Syntax disable gvrp Description The disable gvrp command, along with the enable gvrp command above, is used to enable and disable GVRP on the Switch, without changing t he GVRP configuration on the Switch. Parameters None.
Page 100: Show Gvrp
DGS-3100 Gigabit Ethernet Switch Manual show gvrp Purpose To display the GVRP stat us for a port list or port channel on the Switch. Syntax show gvrp {<portlist> | <ch1-32> ]} Description The show gvrp command displays the GVRP statu s for a port list or a port channel on the Switch.
Page 101: Link Aggregation Commands
GGREGATION OMMANDS The Link Ag gregation commands in the Comma nd Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create link_aggregation group_id <value 1-32> {type [lacp | static]} delete link_a ggregation group _id <value 1-32>...
Page 102: Delete Link_Aggregation
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# delete link_aggregation Purpose To delete a previously configured link aggregation group. Syntax delete link_aggregation group_id <value 1-32> Description The dele te link_aggregation group_id command deletes a previously configured link aggregation group. Parameters group_id <value 1-8> − Specifies the group ID. The Switch allows up to 8 link aggregation groups to be configured.
Page 103: Show Link_Aggregation
S3100# show link_aggregation Purpose To display the current link aggregation configuration on the Switch. Syntax show link_aggregation {gro up_id <value 1-32>} Description The show link_aggregation command displays the current link aggregation configuration of the Switch. Parameters group_id <value 1-32> − Specifies the group ID. The Switch allows up to 32 link aggre gation groups to be configured.
Page 104: Basic Ip Commands
DGS-3100 Gigabit Ethernet Switch Manual IP C ASIC OMMANDS The Basic IP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter [{ipaddress <network_address> | vlan <vlan_name 32> | state [enable | disable]} config ipif system | dhcp] show ipif...
Page 105: Show Ipif
show ipif Purpose To display the configuration of an IP interface on the Switch. Syntax show ipif {system} Description show ipif command displays the configuration of an IP interfac on the Switch Parameters <sy stem> - The name of the IP interface whose settings are to be displ ayed (Always System).
Page 106: Igmp Snooping Commands
DGS-3100 Gigabit Ethernet Switch Manual IGMP S NOOPING OMMANDS he IGMP Snooping commands in the Command Line Interface (CLI) are listed (along with the appropriate para meters) in the following table. Command Parameter [<vlan _name 32> | all] {host_time out <sec 60-16711450> | router_timeout <sec config igm p_snooping 1-167...
Page 107: Config Router_Port
Restrictions Only administrator-level users can issue this command. Example usage: To configure the igmp snooping: DGS3100# config igmp_snoop ing default host_timeout 250 state enable Success. DGS3100 config router_port Purpose To configure ports as router ports. Syntax config router_port <vlan_name 32> [add | delete] <portlist> Description The config router_port comman d designates a range of ports as...
Page 108: Disable Igmp_Snooping
DGS-3100 Gigabit Ethernet Switch Manual Success. DGS3100# disable igmp_snooping Purpose To disable IGMP snooping on the Switch. Syntax disable igmp_snooping Description The disable igmp_snooping command disables IGMP snooping on the Switch. IGMP snooping can be disabled only if IP multicast routing is not being used.
Page 109: Show Igmp_Snooping Group
DGS3100# show igmp_snooping group Purpose To display the current IGMP snooping group configuration on the Switch. Syntax show igmp_snooping group {vlan <vlan_name 32>} Description The show igmp_snooping group command displays the current IGMP snooping group configuration on the Switch. Parameters <vlan_name 32>...
Page 110: Show Router_Port
DGS-3100 Gigabit Ethernet Switch Manual ort Mem otal Ent ries DGS3100# show ro uter_po Purpose To display the currently configured router ports on the Switch. Syntax ow router_port {vlan <vlan_name 32> | static | dynamic} Description The show router_port command displays the router ports currently configured on the Switch.
Page 111: Commands
802.1X C OMMANDS The 802 .1X commands in the Command Line Interface (CLI) are listed (along with th e appropriate parameters) in the following table. Command Parameter enable 802.1x disable 802.1x show 802.1x {ports <portlist>} auth_state show 802.1x {ports <portlist>} auth_configuration [<portlist>...
Page 112: Disable 802.1X
DGS-3100 Gigabit Ethernet Switch Manual Parameters None. Restrictions Only administrator-level users can issue this command. Example usage: To enable 802.1x switch wide DGS3100 # enable 802.1x Success. DGS3 disable 802.1x Purpose To disable the 802.1x server o n the Switch. Syntax disable 802.1x Description...
Page 113: Show 802.1X Auth_Configuration
Parameters ports <portlist> − A port or range of ports whose se ttings are to be displayed. Restrictions Only administrator-level users can issue this command. Example usage: To display the 802.1x authent ication states (stacking disabled) for Port-based 802.1x: DGS3100# sh ow 02.1x auth_state ports 1:1-5 Port Auth PA...
Page 114: Config 802.1X Auth_Parameter Ports
DGS-3100 Gigabit Ethernet Switch Manual packets. ServerTimeout − Shows the length of time to wait for a response from a RADIUS server. MaxReq − Shows the maximum number of times to retry sending packets to the supplicant. ReAuthPeriod − Shows the time interval between successive reauthentications.
Page 115: Config 802.1X Init
<portlist> – A port or range of ports to be co nfigured. Param eters all – Specifies all of the ports on the Switch. default – Returns all of the ports in the specified range to their 802.1x default settings. port_control –...
Page 116: Config 802.1X Auth_Protocol
DGS-3100 Gigabit Ethernet Switch Manual ports <portlist> – A port or range of ports to be configured. all – Specifies all of the ports on the Switch. Restrictions Only administrator-level users can issue this command. Example usage: To initialize the authentication state machine of all ports: DGS3100# config 802.1x init port_based ports all Success.
Page 117: Config Radius Add
DGS3100# config 802.1x reauth port_based ports 1-18 Success. DGS3100# config radius add Purpose To configure the settings the Switch will use to communicate with a RADIUS server. Syntax config radius add [<server_ip>] [key <passwd 32>] [default | {auth_port <udp_port_number 1-65535> | acct_port <udp_port_number 1-65535>}] Description The config radius add command configures the settings the Switch...
Page 118: Config Radius
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# config radius delete 10.48.74.121 Success. DGS3100# config radius Purpose To configure the Switch’s RADIUS settings. Syntax config radius <server_ip> {| key <passwd 32> | auth_port <udp_port_number 1-65535> | acct_port <udp_port_number 1- 65535>} Description The config radius command configures the Switch’s RADIUS settings.
Page 119: Config 802.1X Auth_Mode
DGS3100# show radius Index IP Address Auth-Port Acct-Port Status Number Number -------- ---------------- -------------- -------------- ------------ --------------------- 10.1.1.1 1812 1813 Active switch DGS3100# config 802.1x auth_mode Purpose To configure the 802.1x authentication mode on the Switch. Syntax config 802.1x auth_mode ports <portlist> [port_based | mac_based] Description The config 802.1x auth_mode command enables either the port-...
Page 120: Config Guest_Vlan Ports
DGS-3100 Gigabit Ethernet Switch Manual config guest_vlan ports Purpose Defines a port or range of ports to be members of the Guest VLAN. Syntax config guest_vlan ports <portlist> Description The config guest_vlan ports command defines a port or range of ports to be members of the Guest VLAN.
Page 121: Port Security Commands
ECURITY OMMANDS The Port Security commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter [<portlist> | all] {admin_state [enable | disable] | max_learning_addr <int 0-64> | config port_security trap <interval 1-1000000>} show port_security {<portlist>} Each command is listed in detail, as follows:...
Page 122: Show Port_Security
DGS-3100 Gigabit Ethernet Switch Manual show port_security To display the current port security configuration. Purpose Syntax show port_security {<portlist>} The show port_security command displays port security Description information for the Switch’s ports. The information displayed includes port security, admin state, maximum number of learning address and lock mode.
Page 123: Time And Sntp Commands
SNTP C IME AND OMMANDS The Time and SNTP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter config sntp {primary <ipaddr> | secondary <ipaddr> | poll-interval <int 60-86400>} show sntp enable sntp disable sntp...
Page 124: Show Sntp
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# config sntp primary 10.1.1.1 secondary 10.1.1.2 poll-interval 30 Success. DGS3100# show sntp Purpose To display the SNTP information. Syntax show sntp Description The show sntp command displays SNTP settings information, including the source IP address, time and poll interval. Parameters None.
Page 125: Disable Sntp
disable sntp Purpose To disable SNTP server support. Syntax disable sntp Description The disable sntp command disables SNTP support. SNTP service must be separately configured (see config sntp). Parameters None. Restrictions Only administrator-level users can issue this command. Example usage: To disable SNTP support: DGS3100# disable sntp Success.
Page 126: Config Time_Zone
DGS-3100 Gigabit Ethernet Switch Manual config time_zone Purpose To determine the time zone used in order to adjust the system clock. Syntax config time_zone {operator [+ hour <gmt_hour 0-13> min <minute 0-59> | - hour <gmt_hour 0-12> min <minute 0-59>]} Description The config time_zone command adjusts the system clock settings according to the time zone.
Page 127 expressed numerically. • <hh:mm> - The time of day to begin DST in hours and minutes, expressed using a 24-hour clock. • <week 1-4,last> - The week of the month in which DST ends, where 1 is the first week, 2 is the second week and so on, and last is the last week of the month.
Page 128: Show Time
DGS-3100 Gigabit Ethernet Switch Manual show time Purpose To display the current time settings and status. Syntax show time Description The show time command displays the system time and date configuration, as well as display the current system time. Parameters None.
Page 129: Routing Table Commands
OUTING ABLE OMMANDS The Routing Table commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create iproute [default] <ipaddr> {<metric 1-65535>} delete iproute [default] show iproute Each command is listed in detail, as follows: create iproute Purpose To create IP route entries in the Switch’s IP routing table.
Page 130: Show Iproute
DGS-3100 Gigabit Ethernet Switch Manual Example usage: To delete the default IP route: DGS3100# delete iproute default Success. DGS3100# show iproute Purpose To display the Switch’s current IP routing table. Syntax show iproute Description The show iproute command displays the Switch’s current IP routing table.
Page 131: Arp Commands
ARP C OMMANDS The ARP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create arpentry <ipaddr> <macaddr> config arpentry <ipaddr> <macaddr> delete arpentry [<ipaddr> | all] show arpentry {ipif system | ipaddress <ipaddr>...
Page 132: Delete Arpentry
DGS-3100 Gigabit Ethernet Switch Manual Parameters <ipaddr> − The IP address of the end node or station. <macaddr> − The MAC address corresponding to the IP address above. Restrictions Only administrator-level users can issue this command. Example usage: To configure a static ARP entry for the IP address 10.48.74.12 and MAC address 00:50:BA:00:07:36: DGS3100# config arpentry 10.48.74.12 00-50-BA-00-07-36 Success.
Page 133: Show Arpentry
show arpentry Purpose To display the ARP table. Syntax show arpentry {ipif system | ipaddress <ipaddr> | static } Description The show arpentry command displays the current contents of the Switch’s ARP table. Parameters ipif system <ipif_name 12> – The name of the IP interface, the end node or station for which the ARP table entry was made, resides on.
Page 134: Clear Arptable
DGS-3100 Gigabit Ethernet Switch Manual clear arptable Purpose To remove all dynamic ARP table entries. Syntax clear arptable Description The clear arptable command is used to remove dynamic ARP table entries from the Switch’s ARP table. Static ARP table entries are not affected.
Page 135: Command History List Commands
OMMAND ISTORY OMMANDS The Command History List commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter show command_history config <value 10-237> command_history Each command is listed in detail, as follows: Purpose To display all commands in the Command Line Interface (CLI).
Page 136: Show Command_History
DGS-3100 Gigabit Ethernet Switch Manual config account config admin local_enable config arp_aging time config arpentry config authen application CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All show command_history Purpose To display the command history. Syntax show command_history Description The show command_history command displays the command...
Page 137: Config Command_History
config 802.1p user_priority config 802.1x auth_parameter ports config 802.1x auth_protocol config 802.1x capability ports config 802.1x init config 802.1x reauth config account config admin local_enable config arp_aging time config arpentry config authen application config authen parameter attempt config authen parameter response_timeout config authen server group More: <space>, Quit: q, One line: <return>...
Page 138: Ssh Commands
DGS-3100 Gigabit Ethernet Switch Manual SSH C OMMANDS The SSH commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter enable ssh disable ssh config ssh authmode publickey [enable | disable] show ssh authmode config ssh server { timeout <sec 120-600>...
Page 139: Disable Ssh
disable ssh Purpose To disable SSH. Syntax disable ssh Description The disable ssh command disables SSH on the Switch. Parameters None. Restrictions Only administrator-level users can issue this command. Example usage: To disable SSH: DGS3100# disable ssh Success. DGS3100# config ssh authmode Purpose To configure the SSH authentication mode setting.
Page 140: Config Ssh Server
DGS-3100 Gigabit Ethernet Switch Manual To view the cuurent authentication mode set on the Switch: DGS3100# show ssh authmode The SSH User Authentication Support -------------------------------------------------------------------------- Password : Enabled Publickey : Enabled Hostbased : Enabled DGS3100# config ssh server Purpose To configure the SSH server. Syntax config ssh server { timeout <sec 120-600>...
Page 141: Show Ssh Algorithm
Connection timeout : 120 Authenticate failed attempts Listened Port Number : 22 DGS3100# show ssh algorithm Purpose To display the SSH algorithm setting. Syntax show ssh algorithm Description The show ssh algorithm command displays the current SSH algorithm setting status. Parameters None Restrictions...
Page 142: Show Ssh Crypto
DGS-3100 Gigabit Ethernet Switch Manual <username 1-48> – The username of the remote SSH client. Parameters rsa – Indicates the RSA key pair is manually configured. dsa – Indicates the DSA key pair is manually configured. Restrictions Only administrator-level users can issue this command. Example usage: To specify the SSH public key for the remote SSH client bob: DGS3100# config ssh crypto bob...
Page 143 DGS3100# Delete ssh crypto bob Success. DGS3100#...
Page 144: Ssl Commands
DGS-3100 Gigabit Ethernet Switch Manual SSL C OMMANDS The SSL commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter enable ssl disable ssl show ssl show ssl cachetimeout <number 1-2> generate {key-generate <length 512 - 2048>| cn <common- name 1 - 64>| ou <organization-unit 1 - 64>| or crypto certificate <organization 1 - 64>| loc <location 1 - 64>| st <state 1 - 64>| cu <country 1-2>|...
Page 145: Disable Ssl
DGS3100# disable ssl Purpose To disable the SSL function on the Switch. Syntax disable ssl Description The disable ssl command disables SSL on the Switch and can be used to disable any one or combination of listed ciphersuites on the Switch.
Page 146: Show Ssl Cachetimeout
DGS-3100 Gigabit Ethernet Switch Manual show ssl cachetimeout Purpose To show the SSL cache timeout. Syntax show ssl cachetimeout Description The show ssl cachetimeout command displays the SSL cache timeout currently implemented on the Switch. Parameters None. Restrictions None. Example usage: To view the SSL cache timeout on the Switch: DGS3100# show ssl cachetimeout Cache timeout is 600 seconds.
Page 147: Crypto Certificate (Request)
crypto certificate (request) Purpose To generate and display certificate requests for HTTPS. Syntax crypto certificate <number 1-2> request {cn <common-name 1- 64> | ou <organization-unit 1-64>| or <organization 1-64> | loc <location 1-64> | st <state 1-64>| cu <country 1-2> Description The crypto certificate (request) command exports a certificate request to a Certification Authority.
Page 148: Crypto Certificate (Import)
DGS-3100 Gigabit Ethernet Switch Manual crypto certificate (import) Purpose To import a certificate signed by the Certification Authority for HTTPS. Syntax crypto certificate <number 1-2> import Description The crypto certificate (import) command imports an external certificate (signed by a Certification Authority) to the device. To end the session, enter an empty line.
Page 149: Show Crypto Certificate Mycertificate
show crypto certificate mycertificate Purpose To display the SSH certificates of the device. Syntax show crypto certificate mycertificate {number 1-2} Description The show crypto certificate mycertificate command displays the SSH certificates of the device. Parameters number — Specifies the certificate number (Range: 1 - 2). Restrictions Only administrator-level users can issue this command.
Page 150: Access Authentication Control Commands
DGS-3100 Gigabit Ethernet Switch Manual CCESS UTHENTICATION ONTROL OMMANDS The Access Authentication Control commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter create authen_login <string 12> method_list_name config authen_login [default | method_list_name <string 12>] method {tacacs+ | radius | local | none} delete authen_login <string 12>...
Page 151: Create Authen_Login Method_List_Name
create authen_login method_list_name Purpose To create a user-defined list of authentication methods for users logging on to the Switch. Syntax create authen_login method_list_name <string 12> Description The create authen_login method_list_name command creates a list of authentication techniques for user login. The Switch can support up to eight method lists, but one is reserved as a default and cannot be deleted.
Page 152: Delete Authen_Login Method_List_Name
DGS-3100 Gigabit Ethernet Switch Manual tacacs+ – Specifies that the user is to be authenticated using the TACACS+ protocol from the remote TACACS+ server hosts of the TACACS+ server group list. radius - Specifies that the user is to be authenticated using the RADIUS protocol from the remote RADIUS server hosts of the RADIUS server group list.
Page 153: Show Authen_Login
DGS3100# delete authen_login method_list_name Trinity Success. DGS3100# show authen_login Purpose To display a previously configured user defined method list of authentication methods for users logging on to the Switch. Syntax show authen_login {all | default | method_list_name <string 12>} Description The show authen_login command displays a list of authentication methods for user login.
Page 154: Config Authen_Enable
DGS-3100 Gigabit Ethernet Switch Manual which is defined by the Administrator. A maximum of eight (8) enable method lists can be implemented on the Switch. Parameters <string 12> - Defines the authen_enable method_list_name to be created as a string of up to 12 alphanumeric characters. Restrictions Only administrator-level users can issue this command.
Page 155: Delete Authen_Enable Method_List_Name
• local_enable - Specifies that the user is to be authenticated using the local user account database on the Switch. • none – Specifies that no authentication is required to access the Switch. method_list_name <string 12> – Specifies a previously created authen_enable method_list_name.
Page 156: Show Authen_Enable
DGS-3100 Gigabit Ethernet Switch Manual show authen_enable Purpose To display the list of authentication methods for promoting normal user level privileges to Administrator level privileges on the Switch. Syntax show authen_enable [all | default | method_list_name <string 12>] Description The show authen_enable command deletes a user-defined list of authentication methods for promoting user level privileges to Adminstrator level privileges.
Page 157: Show Authen Application
• console – Configures the command line interface login method. • telnet – Configures the Telnet login method. • ssh – Configures the Secure Shell login method. • all – Configures all applications as (console, Telnet, SSH) login methods. login – Configures an application for normal login on the user level, using a previously configured method list.
Page 158: Create Authen Server_Host
DGS-3100 Gigabit Ethernet Switch Manual create authen server_host Purpose To create an authentication server host. Syntax create authen server_host <ipaddr> protocol [tacacs+ | radius] {port <int 1-65535> | key [<key_string 128> | none] | timeout <int 1-30> | retransmit <int 1-10>} Description The create authen server_host command creates an authentication server host for the TACACS+/RADIUS security...
Page 159: Config Authen Server_Host
config authen server_host Purpose To configure a user-defined authentication server host. Syntax config authen server_host <ipaddr> protocol [tacacs+ | radius] {port <int 1-65535> | key [<key_string 128> | none] | timeout <int 1-30> | retransmit <int 1-10>} Description The config authen server_host command configures a user- defined authentication server host for the TACACS+/RADIUS security protocols on the Switch.
Page 160: Delete Authen Server_Host
DGS-3100 Gigabit Ethernet Switch Manual delete authen server_host Purpose To delete a user-defined authentication server host. Syntax delete authen server_host <ipaddr> protocol [tacacs+ | radius] Description The delete authen server_host command deletes a user-defined authentication server host previously created on the Switch. Parameters server_host <ipaddr>...
Page 161: Local_Enable Admin
DGS3100# show authen server_host IP Address Protocol Port Timeout Retransmit Key --------------- ------------ ------ ----------- --------------- ------------------ 10.53.13.94 TACACS --------- Total Entries : 1 DGS3100# local_enable admin Purpose To promote user level privileges to administrator level privileges. Syntax local_enable admin Description The local_enable admin command enables a user to be granted administrative privileges on to the Switch.
Page 162 DGS-3100 Gigabit Ethernet Switch Manual Parameters None. Restrictions Only administrator-level users can issue this command. Example usage: To configure the password for the “local_enable” authentication method. DGS3100# config admin local_enable Enter the old password: Enter the case-sensitive new password:****** Enter the new password again for confirmation:****** Success.
Page 163: Lacp Commands
LACP C OMMANDS The LACP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter config lacp port_priority <portlist> [priority 1-65535] [timeout <90sec | 3sec>] show lacp {<portlist>} Each command is listed in detail, as follows: config lacp port_priority Purpose To set the priority value of a physical port in an LACP group.
Page 164 DGS-3100 Gigabit Ethernet Switch Manual If no parameter is specified, the system displays the current LACP status for all ports. Restrictions None Example usage: To display LACP port mode settings: DGS3100# show lacp Port Priority Timeout ------ ----------- ------------ 90 sec 90 sec 90 sec 90 sec...
Page 165: Stacking Commands
TACKING OMMANDS The Stacking commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter config box_id current_box_id <value 1-6> new_box_id [auto | 1 | 2 | 3 | 4 | 5 | 6] show stack_information config box_id Purpose...
Page 166 DGS-3100 Gigabit Ethernet Switch Manual DGS3100# show stack_information Master ID Backup ID : 2 Box ID User Set Boot version Firmware version H/W version --------- ------------ ------------------ ------------------------ ----------------- Auto 1.0.0.03 1.0.0.28 00.00.01 1.0.0.03 1.0.0.28 00.00.01 DGS3100#...
Page 167: Poe Commands
OMMANDS The PoE commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter box_id <value 1-6> system_power_limit [ps1 | ps2 | ps3] disconnect_method config poe [deny_next_port | deny_low_priority_port] <portlist> { state [enable | disable] | priority [low | high | critical] | power_limit config poe ports <value 1-15400>} show poe...
Page 168: Config Poe Ports
DGS-3100 Gigabit Ethernet Switch Manual DGS3100# config poe ports Purpose To configure the PoE port settings. Syntax config poe ports <portlist> { state [enable | disable] | priority [ low | high | critical ] | power_limit <value 1-15400>} Description The config poe ports command configures PoE settings for a port or range of ports.
Page 169 Parameters None. Restrictions None. Example usage: To display the power settings for the Switch: DGS3100# show poe Port State Priority Power Limit --------- ----------- -------------- ----------------------- DGS3100#...
Page 170: Access Control List Commands
DGS-3100 Gigabit Ethernet Switch Manual CCESS ONTROL OMMANDS The Access Control List commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter profile_id <value 1-15> [ethernet {vlan | source_mac <macmask 000000000000- create access_profile ffffffffffff>...
Page 171: Create Access_Profile (Ip)
Parameters profile_id <value 1-15> – Specifies an index number between 1 and 15 that identifies the access profile being created with this command. ethernet - Specifies that the Switch examine the layer 2 part of each packet header with emphasis on one or more of the following: •...
Page 172: Config Access_Profile (Ethernet)
DGS-3100 Gigabit Ethernet Switch Manual for the source IP address. • destination_ip_mask <netmask> – Specifies an IP address mask for the destination IP address. • dscp – Specifies that the Switch examine the DiffServ Code Point (DSCP) field in each frame’s header. •...
Page 173 using a logical AND operational method, with the values the Switch finds in the specified frame header fields. Syntax config access_profile profile_id <value 1-15> [add access_id [auto assign | <value 1-255>] [ethernet {vlan <vlan_name 32> | source_mac <macaddr 000000000000-ffffffffffff> | destination_mac <macaddr 000000000000-ffffffffffff>...
Page 174: Config Access_Profile (Ip)
DGS-3100 Gigabit Ethernet Switch Manual to limit Rx bandwidth for for the profile being configured. This rate is implemented using the following equation – 1 value = 64kbit/sec. (ex. If the user selects a rx rate limit of 10 then the ingress rate is 640kbit/sec.) The user many select a value between 3500- 1000000 or no limit.
Page 175 • destination_ip <ipaddr> – Specifies that the access profile applies only to packets with this destination IP address. • dscp <value 0-63> – Specifies that the access profile applies only to packets that have this value in their Type-of- Service (DiffServ code point, DSCP) field in their IP packet header.
Page 176: Config Access_Profile
DGS-3100 Gigabit Ethernet Switch Manual the criteria specified in the first part of the command. This value will over-write the value in the DSCP field of the packet. • rate_limit <value 3500-1000000> – Specifies the rate limit to limit Rx bandwidth for for the profile being configured. This rate is implemented using the following equation –...
Page 177: Show Access_Profile
Syntax delete access_profile profile_id <value 1-15> Description The delete access_profile command deletes a previously created access profile on the Switch. Parameters profile_id <value 1-15> – Specifies the access profile to be deleted. This value is assigned to the access profile when it is created with the create access_profile command.
Page 178 DGS-3100 Gigabit Ethernet Switch Manual Ports: 2 -------------------- ====================================================================== Total Entries: 2 DGS3100#...
Page 179: Traffic Segmentation Commands
RAFFIC EGMENTATION OMMANDS The Traffic Segmentation commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameter config [<portlist> | <ch1-32>] forward_list [null | <portlist> | <ch1-32>] traffic_segmentation show traffic_ {<portlist>} segmentation Each command is listed in detail, as follows: config traffic_segmentation...
Page 180 DGS-3100 Gigabit Ethernet Switch Manual traffic segmentation configuration on the Switch. Parameters <portlist> – A port or range of ports for which the current traffic segmentation configuration on the Switch is to be displayed. Restrictions The port lists for segmentation and the forward list must be on the same Switch.
Page 181: Device Specifications
EVICE PECIFICATIONS This appendix contains the device specifications, and contains the following topics: • Technical Specifications • Cable Lengths Technical Specifications Performance Store-and-forward Transmission Method 512Kbytes per device RAM Buffer Full-wire speed for all connections. Packet Filtering/ Forwarding Rate 1,488,095 pps per port (for 1000Mbps) Automatic update.
Page 182 DGS-3100 Gigabit Ethernet Switch Manual General IEEE 802.3 10BASE-T Ethernet Standards IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z Gigabit Ethernet IEEE 802.1Q Tagged VLAN IEEE 802.1P Tagged Packets IEEE 802.3ab 1000BASE-T IEEE 802.3x Full-duplex Flow Control ANSI/IEEE 802.3 NWay auto-negotiation CSMA/CD Protocols Half-duplex...
Page 183: Cable Lengths
Cable Lengths Use the following table to as a guide for the maximum cable lengths: Standard Media Type Maximum Distance DEM-310GT: SFP Transceiver for 1000BASE-LX, Single-mode fiber 10km Mini GBIC module DEM-311GT: SFP Transceiver for 1000BASE-SX, Multi-mode fiber module 550m DEM-314GT: SFP Transceiver for 1000BASE-LHX, Single-mode fiber 40km module...
Page 184: Limited Warranty
Hardware. The Warranty Period shall extend for an additional ninety (90) days after any repaired or replaced Hardware is delivered. If a material defect is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to repair or replace the defective Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
Page 185 D-Link to confirm the same. The original product owner must obtain a Return Material Authorization (RMA) number from the Authorized D-Link Service Office and, if requested, provide written proof of purchase of the product (such as a copy of the dated purchase invoice for the product) before the warranty service is provided.
Page 186: Fcc Warning
Trademarks Copyright 2006 D-Link Corporation. Contents subject to change without prior notice. D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective proprietors.
Page 187: Registration Card
8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chainstore/Wholesale Government Transportation/Utilities/Communication System house/company Other_________________________________________________________________________ 9. Would you recommend your D-Link product to a friend? Don't know yet 10.Your comments on this product? _____________________________________________________________ ___________________________________________________________________________________________________________________________ ___________________________________________________________________________________________________________________________ _______________________________________________________________...
Page 189 The customer must submit with the product as part of the claim a written description of the Hardware defect or Software nonconformance in sufficient detail to allow D-Link to confirm the same, along with proof of purchase of the product (such as a copy of the dated purchase invoice for the product) if the product is not registered.
Page 190 Trademarks: D-Link is a registered trademark of D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective owners. Copyright Statement: No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the...
Page 191 Product Registration: Register online your D-Link product at http://support.dlink.com/register/ Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.
Page 192: Tech Support
Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within Australia: D-Link Technical Support over the Telephone: 1300-766-868 Monday to Friday 8:00am to 8:00pm EST Saturday 9:00am to 1:00pm EST D-Link Technical Support over the Internet: http://www.dlink.com.au...
Page 193: Technical Support
You can find software updates and user documentation on the D-Link website. Tech Support for customers within South Eastern Asia and Korea: D-Link South Eastern Asia and Korea Technical Support over the Telephone: +65-6895-5355 Monday to Friday 9:00am to 12:30pm, 2:00pm-6:00pm...
Page 194 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within India D-Link Technical Support over the Telephone: +91-22-26526741 +91-22-26526696 –ext 161 to 167 Monday to Friday 9:30am to 7:00pm D-Link Technical Support over the Internet: http://ww.dlink.co.in...
Page 195 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers for the duration of the warranty period on this product. Customers can contact D-Link technical support through our web site or by phone.
Page 196 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within the U.A.E & North Africa: D-Link Technical Support over the Telephone: (971) 4-391-6480 (U.A.E) Sunday to Wednesday 9:00am to 6:00pm GMT+4 Thursday 9:00am to 1:00pm GMT+4 D-Link Middle East &...
Page 197 You can find software updates and user documentation on the D-Link website. Tech Support for customers within South Africa and Sub Sahara Region: D-Link South Africa and Sub Sahara Technical Support over the Telephone: +27-12-665-2165 08600 DLINK ( For South Africa only )
Page 198 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for Latin America customers: D-Link Technical Support over the followings Telephones: Argentina: 0-800 122 35 465 Monday to Friday 09:00am to 22:00pm Chile: 800-835465...
Page 199 Техническая поддержка Обновления программного обеспечения и документация доступны на Интернет-сайте D-Link. D-Link предоставляет бесплатную поддержку для клиентов в течение гарантийного срока. Клиенты могут обратиться в группу технической поддержки D-Link по телефону или через Интернет. Техническая поддержка D-Link: (495) 744-00-99 Техническая поддержка через Интернет...
Page 200 El servicio de soporte técnico tiene presencia en numerosos países de la Región Latino América, y presta asistencia gratuita a todos los clientes de D-Link, en forma telefónica e internet, a través de la casilla soporte@dlinkla.com Soporte Técnico Help Desk Argentina: Teléfono: 0-800 122 35 465 Lunes a Viernes 09:00 am a 22:00 pm...
Page 201 Você pode encontrar atualizações de software e documentação de usuário no site da D-Link Brasil www.dlinkbrasil.com.br. A D-Link fornece suporte técnico gratuito para clientes no Brasil durante o período de vigência da garantia deste produto. Suporte Técnico para clientes no Brasil: Telefone São Paulo (11) 2185-9301...
Page 202 D-Link 友訊科技台灣分公司技術支援資訊如果您還有任何本使用手冊無法協助您解決的產品相關問題，台灣地區用戶可以透過我們的網站、電子郵件或電話等方式與D-Link台灣地區技術支援工程師聯絡。 D-Link 免付費技術諮詢專線 0800-002-615 服務時間：週一至週五，早上8:30 到晚上7:00 (不含周六、日及國定假日) 網站：http://www.dlink.com.tw 電子郵件：dssqa_service@dlink.com.tw 如果您是台灣地區以外的用戶，請參考D-Link網站全球各地分公司的聯絡資訊以取得相關支援服務。產品保固期限、台灣區維修據點查詢，請參考以下網頁說明： http://www.dlink.com.tw 產品維修：使用者可直接送至全省聯強直營維修站或請洽您的原購買經銷商。...
Page 203 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the service period, and warranty confirmation service, during the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
Page 204 Technical Support You can find software updates and user documentation on the D-Link websites. If you require product support, we encourage you to browse our FAQ section on the Web Site before contacting the Support line. We have many FAQ’s which we hope will provide you a speedy resolution for your problem.
Page 205 0,12€/Min aus dem Festnetz der Deutschen Telekom. Telefonische technische Unterstützung erhalten Sie Montags bis Freitags von 09.00 bis 17.30 Uhr. Unterstützung erhalten Sie auch bei der Premiumhotline für D-Link Produkte unter der Rufnummer 09001-475767 Montag bis Freitag von 6-22 Uhr und am Wochenende von 11-18 Uhr.
Page 206: Assistance Technique
Vous trouverez la documentation et les logiciels les plus récents sur le site web D-Link. Vous pouvez contacter le service technique de D-Link par notre site internet ou par téléphone. Support technique destiné aux clients établis en France: Assistance technique D-Link par téléphone : 0820 0803 03 N°...
Page 207 Asistencia Técnica Puede encontrar las últimas versiones de software así como documentación técnica en el sitio web de D-Link. D-Link ofrece asistencia técnica gratuita para clientes residentes en España durante el periodo de garantía del producto. Asistencia Técnica de D-Link por teléfono:...
Page 208 Supporto tecnico Gli ultimi aggiornamenti e la documentazione sono disponibili sul sito D-Link. Supporto tecnico per i clienti residenti in Italia D-Link Mediterraneo S.r.L. Via N. Bonnet 6/B 20154 Milano Supporto Tecnico dal lunedì al venerdì dalle ore 9.00 alle ore 19.00 con orario continuato Telefono: 02-39607160 URL : http://www.dlink.it/supporto.html...
Page 209 Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within Benelux for the duration of the warranty period on this product. Benelux customers can contact D-Link technical support through our website, or by phone.
Page 210: Pomoc Techniczna
Pomoc techniczna Najnowsze wersje oprogramowania i dokumentacji użytkownika można znaleźć w serwisie internetowym firmy D-Link. D-Link zapewnia bezpłatną pomoc techniczną klientom w Polsce w okresie gwarancyjnym produktu. Klienci z Polski mogą się kontaktować z działem pomocy technicznej firmy D-Link za pośrednictwem Internetu lub telefonicznie.
Page 211 Technická podpora Aktualizované verze software a uživatelských příruček najdete na webové stránce firmy D-Link. D-Link poskytuje svým zákazníkům bezplatnou technickou podporu Zákazníci mohou kontaktovat oddělení technické podpory přes webové stránky, mailem nebo telefonicky Web: http://www.dlink.cz/suppport/ E-mail: support@dlink.cz Telefon: 224 247 503 Telefonická...
Page 212 Technikai Támogatás Meghajtó programokat és frissítéseket a D-Link Magyarország weblapjáról tölthet le. Telefonon technikai segítséget munkanapokon hétfőtől-csütörtökig 9.00 – 16.00 óráig és pénteken 9.00 – 14.00 óráig kérhet a (1) 461-3001 telefonszámon vagy a support@dlink.hu emailcímen. Magyarországi technikai támogatás : D-Link Magyarország...
Page 213 Teknisk Support Du kan finne programvare oppdateringer og bruker dokumentasjon på D-Links web sider. D-Link tilbyr sine kunder gratis teknisk support under produktets garantitid. Kunder kan kontakte D-Links teknisk support via våre hjemmesider, eller på tlf. Teknisk Support: D-Link Teknisk telefon Support:...
Page 214 Teknisk Support Du finder software opdateringer og bruger- dokumentation på D-Link’s hjemmeside. D-Link tilbyder gratis teknisk support til kunder i Danmark i hele produktets garantiperiode. Danske kunder kan kontakte D-Link’s tekniske support via vores hjemmeside eller telefonisk. D-Link teknisk support over telefonen: D-Link teknisk support over telefonen: Tlf.
Page 215 Teknistä tukea asiakkaille Suomessa: D-Link tarjoaa teknistä tukea asiakkailleen. Tuotteen takuun voimassaoloajan. Tekninen tuki palvelee seuraavasti: Arkisin klo. 9 - 21 numerosta 0800-114 677 Internetin kautta Ajurit ja lisätietoja tuotteista. http://www.dlink.fi Sähköpostin kautta voit myös tehdä kyselyitä.
