5.2

Testing Network Configuration

After you configure the Network properties and restart HD3000, you can check that
the changes that you made were applied.
To check network configuration
1. Press <Status>. The Status dialog box appears.
The Status dialog box informs you if your HD3000 is connected
with the local LAN and if the HD3000 is registered with a
Gatekeeper and/or an MXM.
2. Check that the IP Address displayed is the one that you set or received for
the system.
3. Check if the system is logged into an MXM or registered with a
Gatekeeper, depending on the H.323 options that you chose.
If you selected Gatekeeper and entered the correct IP address in the
Network dialog box's H.323 tab, the HD3000 should be registered in the
Gatekeeper. If it is not, change the User Number that you entered. You
might have entered a number that is already occupied.
For more troubleshooting details, press the green DIAGNOSE
SoftKey
Emblaze VCON HD3000 User's Guide
(see"System Diagnostics" on page
Chapter 5 Network Configuration
147).
75
