Connecting an Audio Mixer
Connecting an audio mixer lets you add several audio inputs to the HD3000.
These instructions are applicable to most audio mixers available in the
marketplace. For specific instructions on installing and operating the audio
mixer, see its accompanying user's guide.
To connect an audio mixer to the HD3000
1.
Connect all audio sources (microphones, DVD/VCR, etc.) to the mixer.
2.
Connect an unbalanced mono cable between the Mono LINE OUT
connector of the mixer and the HD3000's AUX connector.
3.
Since connection to the HD is through a single line, configure the mixer
for mono (or monophonic) sound production.
Connecting an Audio Mixer and Audio Components to the HD3000
Emblaze VCON HD3000 User's Guide
Chapter 2 Setting Up HD3000
33
