LAN Connection

In the LAN tab, enter the HD3000's address and information about its connection
to the LAN (Local Area Network).
Automatically
Obtain IP
IP Address
Subnet Mask
DNS Server
&
WINS Server
Domain
Default Gateway IP address of the network's Gateway router. The gateway
MAC Address
Emblaze VCON HD3000 User's Guide
Select to enable HD3000 to receive its network
configuration from the LAN's DHCP server and enter it
automatically in the LAN tab.
If this option is not selected, you have to enter the LAN
properties manually. Consult with your system
administrator.
If your HD3000 receives an address automatically, it is a
temporary address which is liable to be changed when
the network's users' IP addresses are updated
periodically.
If you manually enter an IP address here, the address
remains permanently.
Your company's subnet mask.
IP Addresses of the DNS server and the WINS server.
Registering with these servers enables HD3000 to
translate names to IP addresses.
DNS domain name of your company (for example,
bestcorp.com).
helps HD3000 send and receive calls between subnets.
The unique Media Access Control (MAC) address of
your HD3000 device.
Chapter 5 Network Configuration
65
