Chapter 2 Setting Up HD3000
Connecting a Stationary Camera
To connect additional stationary cameras
If you are using only one additional camera, we recommend that you use
the S-Video connection, which supplies higher quality video.
If you connect two additional cameras, do not connect the S-Video and
Composite cables to the same camera, which causes degraded video
quality. Instead, set one up for S-Video and the other one for Composite
video.
Connect an S-Video cable between the S-Video connector of the camera
and the system's CAM1 connector.
-or-
Connect a Composite video cable between the Video connector of the
camera and the system's CAM2 connector.
28
Connecting HD3000 to Stationary Cameras
Emblaze VCON HD3000 User's Guide
