Emblaze-VCON HD3000 User Manual page 144

Chapter 12 Telephony Exchange Functions
2. Navigate to the H.323 tab and press the right arrow button to
access H.323 properties.
3. Select the MXM option.
4. In the MXM Server IP box, enter the IP address of the MXM.
Select to enable the system
to register with the MXM
H.323
tab
5. Press <OK> twice. A message states that HD3000 will restart in a
few seconds.
If the MXM is in Open mode, it automatically permits the HD3000 to
register or log in.
If the login attempt is unsuccessful, consult with the system administrator.
The administrator must then grant login permission before the HD3000
can log in.
132 Emblaze VCON HD3000 User's Guide
Enter the IP address
of the MXM
OK
