AT A GLANCE

Get acquainted with your CubeX 3D Printer before you begin printing. This section identifies the important areas that will be
discussed throughout this guide .
CubeX Duo is depicted for illustration purposes only . Locations of important areas are the same for the Cube X and Cube X
Trio .
F
Touchscreen
A
Function button
B
Jet Wiper
C
Z-axis
D
Print Pad & Print Plate
E
Memory stick USB port and PC connection USB port
F
Power supply
G
Print Jet 1
H
A
B
C
D
E
Front
G
Bottom
H I
Underneath top cover
H I
K L
Top area, inside printer
N
Bottom area, inside printer
Print Jet 2
I
Print Jet 3
J
Print Jet Tip 1
K
Print Jet Tip 2
L
Print Jet Tip 3
M
Material Cartridge Bay 1 (for Print Jet 1)
N
Material Cartridge Bay 2 (for Print Jet 2)
O
Material Cartridge Bay 3 (for Print Jet 3)
P
6
J
J
M
O P
