FINISHING YOUR CREATION

REMOVING YOUR CREATION FROM THE PRINT PAD

Before you attempt to remove your creation from the Print Pad, please ensure that the CubeX has finished
!
printing and that the Print Pad has moved to the bottom of the CubeX.
1 . Lift the Print Pad from the side and pull up to remove the Print Pad from the
CubeX .
2 . Submerge Print Pad and the base of the part in warm water for five minutes.
(Fig . 92) If you do not have the ability to submerge the Print Pad place Print Pad
in sink and let hot water run over the base of the part for about 5 minutes .
3 . Using the scraper (included in tool kit), gently release your creation from the
glass . (Fig . 93)
4 . Rinse your creation under hot water to ensure all of the Magic CubeX Glue paste has been removed .
5 . To clean the Print Pad, rinse the pad under hot water to clean off any remaining Magic CubeX Glue paste .
6 . Dry the Print Pad thoroughly before reinstalling it into CubeX .

REMOVING RAFTS

A raft is the flat support structure that is attached to your creation. Though we recommend printing without a raft, some larger
or more complicated parts may require one . If you print with a raft, the following instructions will help you remove it:
ABS RAFT / PLA PART - PLA RAFT / ABS PART
ABS RAFT / ABS PART - PLA RAFT / PLA PART

REMOVING SUPPORTS WITH WIRE CUTTERS

Use wire cutters to cut away the support structure from your model . You should cut the supports at the point where they
touch the model .
ABS rafts can be peeled away from PLA parts .
Use pliers to pull away as much of the raft as possible .
Then use a rough-grade sandpaper to remove the
remaining raft, followed by a fine-grade wet and dry
sandpaper to achieve a smoother finish.
26
Fig . 92
Fig . 93
