EXTRUDER CARRIAGE ASSEMBLY
A
B
C
D
G
3D Systems, Inc.
E
D
C
B
A
Delivery Tube Bracket
Delivery Tube Nut 1
Delivery Tube 1
Delivery Tube Nut 2
E
Delivery Tube 2
F
Delivery Tube Nut 3
Delivery Tube 3
G H
F
L
H
Delivery Tube Block
I
Extruder 1
J
Extruder 2
K
Extruder 3
L
Print Jet Cooling Fan
M
Creation Cooling Fan
4
I
J
K
M
M
Front
