UNPACKING YOUR CUBEX

1 . Open the box and remove the top acrylic lid located between two layers of foam . Set
aside the two foam inserts for future packing . (Fig . 1)
2 . With two people, remove CubeX from the box, lift from the metal frame on both sides
of the printer . Place CubeX on a table . (Fig . 2)
3 . Remove the material cartridges and tool kit from the bottom of box . (Fig . 3)
4 . Using the snips located in the tool kit, cut blue straps away from cardboard . Cut away
all blue zip ties securing the printer carriage. (Fig. 4)
5 . Using the snips, cut away all yellow zip ties securing the foam parts in place.
Remove foam packing material . (Fig . 5)
6 . Remove all foam fittings. (Fig. 6)
8
Fig . 1
Fig . 2
Fig . 3
Fig . 4
Fig . 5
Fig . 6
