VIEW TAB

ZOOM
VIEW
PRINT PATHS

SETTINGS TAB

PRINTER
CONFIGURATION
BUILD SETTINGS
FIRMWARE UPDATE
CREATION FILE PREPARATION & PRINTING YOUR CREATIONS
WARNING: PRINT JET TIPS BECOME EXTREMELY HOT DURING SET-UP AND OPERATION. DO NOT
TOUCH PRINT JET TIP.
!
DO NOT CHANGE CARTRIDGE COLOR OR MATERIAL TYPE DURING PRINTING; DOING SO MAY DAMAGE
THE CUBEX.

HOW TO OPEN FILES IN THE CUBEX SOFTWARE

The CubeX software has three different possible ways to open .stl files. A single part file, multiple single part files on one
Print Pad and a multi-part file assembly.
• A single part file consists of one .stl file with one shell on a Print Pad.
Zoom In
Zoom Out
Top View
Front View
Left View
Right View
Show Print Jet 1
Show Print Jet 2
Show Print Jet 3
Show All Layers
Opens the printer configuration window.
Opens the build settings window .
Used to update the CubeX 3D Printer firmware.
Press to zoom in
Press to zoom out
Press to view the part from above
Press to view the part from the front
Press to view the part from the left
Press to view the part from the right
Toggle to show the print paths for print jet
1 in a .cubex file
Toggle to show the print paths for print jet
2 in a .cubex file
Toggle to show the print paths for print jet
3 in a .cubex file
Toggle to show all layers or to show one
layer at a time . Scroll through the layers
using the scroll bar found down the right
hand side of the window
