3D Systems CubeX Duo User Manual page 34

7 . Press the tick on the screen to put the CubeX 3D Printer into boot
loader mode . (Fig . 112 & 113) . Release the function button after
"Setting saved" message disappears. Your printer is now in firmware
mode .
8 . Remove the USB stick from the CubeX 3D Printer . (Fig . 114)
9 . Open the CubeX software on your computer . (Fig . 115)
10 . Plug your CubeX into the computer using the PC connection USB
port . (Fig . 116 & 117)
11 . Navigate to the settings tab to the CubeX software and press the Firmware update button .
(Fig . 118)
12 . The CubeX software will then open windows explorer . Navigate to the
firmware you wish to install and open it. (Fig. 119)
13 . The CubeX software will now install the firmware onto the CubeX printer. (Fig.
120)
14 . Once the firmware is installed unplug the printer from the main power for
30 seconds and unplug the USB from the computer . (If you are upgrading
from firmware version 1.01, please skip to the section RESTORING THE
SETTINGS TO YOUR CUBEX 3D PRINTER FIRMWARE FROM V1 .01)
Fig . 112
Fig . 114
Fig . 116
33
Fig . 113
Fig . 115
Fig . 117
Fig . 118
Fig . 119
Fig . 120
