REMOVING THE REMAINING PACKAGING MATERIALS
1 . Using left / right arrows on the touch screen, navigate to the MOVE menu . (Fig . 18)
2 . Using the up arrow on the right side of screen, move the print plate up far enough to
remove the foam . (Fig . 19)
3 . Remove the last foam piece underneath the build plate . (Fig . 20)
4 . Move the Print Pad all the way down to install the Jet Wiper . (Fig . 21)
5 . To install the Print Wiper, insert the wiper's two key holes onto the two rods located
at the back, right side of printer . The wiper's white plastic piece and spring should be
facing the front . (Fig . 22)
11
Fig . 18
Fig . 19
Fig . 20
Fig . 21
Fig . 22
